5000W Pure Sine Wave Hybrid Inverter with 80Amp MPPT Controller for Solar Energy System
- Category: >>>
- Supplier: Beijing Multifit Electrical Technology Co. Ltd.
Share on (62548543541):
Product Overview
Description
5000 Watt High Efficiency Off Grid Pure Sine Wave 80Amp MPPT Controller DC to AC Pure Sine Wave Inverter
1.Output Power Factor 1.0
2. Wide PV Input Range Up to 500VDC
3. Batteryless Support, Work without Battery Daytime
4. Pure Sine Wave Inverter
5. Selectable High Power Charging Current
6. Selectable AC Input Voltage Range for Home Appliances and Personal Computers
7. Configurable AC/Solar Input Priority via LCD Setting
3. Batteryless Support, Work without Battery Daytime
4. Pure Sine Wave Inverter
5. Selectable High Power Charging Current
6. Selectable AC Input Voltage Range for Home Appliances and Personal Computers
7. Configurable AC/Solar Input Priority via LCD Setting
8. Compatible with Mains Voltage or Generator Power
9. Auto Restart while AC is Recovering
10. Cold Start Function
11. Overload and Short Circuit Protection
12. Smart Battery Charge Design for Optimized Battery Performance
11. Overload and Short Circuit Protection
12. Smart Battery Charge Design for Optimized Battery Performance
Specification
MODEL | SuninvM HF Pro 3KVA/24V | SuninvM HF Pro 5KVA/48V | ||
Rated Power | 3KVA/3KW | 5KVA/5KW | ||
PV INPUT (DC) | ||||
Max. PV Array Power | 4000W | |||
Norminal PV Voltage | 240VDC | |||
PV Array MPPT Voltage Range | 120VDC~450VDC | |||
Max. PV Open Circuit Voltage | 500VDC | |||
Max. Charging Current | 80Amp | 24V/20-32V 48V/40-64V | ||
AC OUTOUT (AC) | ||||
Voltage | 180VAC±7V(UPS)；100VAC±7V(Appliances) | 540X250X196 | ||
High Loss Voltage | 280VAC±7V | |||
High Loss Return Voltage | 270VAC±7V | |||
Max. AC Input Voltage | 300VAC | |||
Norminal Input Frequency | 50HZ/60HZ (Auto Detection) | |||
Transfer Time | 10ms typical(UPS); 20ms typical(Appliances) | |||
BATTERY OUTPUT (AC) | ||||
Norminal Output Power | 3KVA/3KW | 5KVA/5KW | ||
Surge Power | 6000W | 10000W | ||
Normial Output Voltage | 230VAC±5% | |||
Output Waveform | Pure Sine Wave | |||
Efficiency (DC to AC)(Peak) | 93% | |||
PHYSICAL | ||||
Dimension (D*W*H) | 100*300*400 mm | |||
Net Weights | 9 Kgs | 10 Kgs | ||
Communication Port | RS-232/USB | |||
ENVIRONMENT | ||||
Humidity | 5 ~ 95% RH (Non Condensing) | |||
Operating Temperature | -10°C ~ 55°C | |||
Altitude | 0 ~ 1000 m | |||
Product Images
Company Profie
Multifit is expert with ISO9001:2008 on manufacturing TUV, CE, SONCAP & CCC solar products to over 60 countires for 10 years, covering solar inverters, solar cleaning robots, solar street lights, ect.
And, Multifit has experienced designing and installation teams on solar system, either off grid or on grid. This ability can help us better support our customer's capability to win new sales and do an excellent maintenance.
Come with MULTIFIT, to power a better world!
And, Multifit has experienced designing and installation teams on solar system, either off grid or on grid. This ability can help us better support our customer's capability to win new sales and do an excellent maintenance.
Come with MULTIFIT, to power a better world!
Exbihition Shows
FAQ
Q1: Are you a factory or trading company?
Q2: Where is your factory located? How can I visit there?
Q3: How can I get some samples?
Q4: How do you ship the goods and how long does it take to arrive?
Q5: Where is your loading port?
Q6: How long is your factory delivery time?
Q7: Is it OK to print my logo on the product?
Q8: Do you offer guarantee for the products?
A: We are a factory. Multifit Solar is an original design manufacturer of power inverter, the solar charge controller and solar array box since 2009.
Q2: Where is your factory located? How can I visit there?
A: Our factories are located in BeiJing and Shantou City, Guangdong, China. Its takes half hours from Airport or Train Station. Welcome to visit our technology development and production lines at your free time!
Q3: How can I get some samples?
A: We can provide you samples for quality checking. Kindly contact us for getting more discount and profitable project solutions.
Q4: How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. Airline and sea shipping also optional.
Q5: Where is your loading port?
A: Multifit have 2 factories in Beijing and Shantou City Guangdong. The loading port is TianJin/ Shanghai or Shenzhen/ Guangzhou for optional.
Q6: How long is your factory delivery time?
A: 3-7 days for sample order, 5-10 days for MOQ order,15-30 days for 20ft container.
Q7: Is it OK to print my logo on the product?
A: Yes. Please inform us formally before production and confirm the design firstly based on our sample.
Q8: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
