mechanical lift table scissor lift table 100kg 300kgsscissor lift table supplier
- Category: >>>
- Supplier: Zhejiang Zhongbei Machinery Co. Ltd.
Share on (62551267387):
Product Overview
Description
Product Description
Features:
Lift Table ZMPT series
1. Heavy Duty Design
2. ZMPT series lift tables meet EN norm and ANSI/ASME safety standards.
3. These models can be used in above-floor or in-floor pit applications.
Lift Table ZMPT series
1. Heavy Duty Design
2. ZMPT series lift tables meet EN norm and ANSI/ASME safety standards.
3. These models can be used in above-floor or in-floor pit applications.
specification
STANDARD ZMPT SERIES LIFT TABLES | ||||||||||
MODEL | ZMPT150 | ZM300 | ZM500 | ZM800 | ZM1000 | |||||
LOAD CAPACITY (KG) | 150 | 300 | 500 | 800 | 1000 | |||||
LOWEST HEIGHT (MM) | 210 | 280 | 280 | 415 | 415 | |||||
MAX.HEIGHT (MM) | 720 | 900 | 900 | 1000 | 1000 | |||||
TABLE DIMENSIONS (MM) | 700*450*35 | 815*500*50 | 815*500*50 | 1016*510*60 | 1016*510*60 | |||||
DIA.OF THE WHEEL (MM) | 100 | 125 | 125 | 150 | 150 | |||||
NET WEIGHT (KG) | 40 | 74 | 84 | 112 | 112 | |||||
HANDLE HEIGHT OFF THE GROUD(MM) | 810 | 970 | 970 | 990 | 990 | |||||
STANDARD ZMPTS SERIES LIFT TABLES | ||||||||||
MODEL | ZMPT150 | ZM350 | ZM500 | ZM800 | ZM1000/1500 | |||||
LOAD CAPACITY (KG) | 150 | 350 | 500 | 800 | 1000/1500 | |||||
LOWEST HEIGHT (MM) | 302 | 360 | 360 | 450 | 500 | |||||
MAX.HEIGHT (MM) | 1260 | 1300 | 1500 | 1500 | 1700 | |||||
TABLE DIMENSIONS (MM) | 700*450*35 | 905*500*50 | 905*500*50 | 1380*610*460 | 1200*610*80 | |||||
DIA.OF THE WHEEL (MM) | 40 | 40 | 120 | 150 | 150 | |||||
NET WEIGHT (KG) | 50 | 108 | 110 | 150 | 225/280 | |||||
HANDLE HEIGHT OFF THE GROUD(MM) | 810 | 970 | 980 | 980 | 1000 | |||||
Certifications
Packing & Delivery
1.The unit hand pallet truck packs in card case.
2.6 set to a group. Each group packs in wooden pallet and thick plastic sheeting with air cushion.
2.6 set to a group. Each group packs in wooden pallet and thick plastic sheeting with air cushion.
Company Profie
ZHEJIANG ZHONGBEI EQUIPMENT CO, LTD.(hereinafter referred to as ZHONGBEI), with headquarter in Hangzhou and factory in Tongxiang,Zhejiang Province, China, is a company specialized in manufacturing and designing many kinds of warehouse equipment and material handling equipment, such as collapsible steel pallets, hand trolleys, steel racks, display stands, etc.
With the faith of"Sincerity, Practice, Cooperation Creativity", ZHONGBEI staff alwayskeep in mind, from the very beginning, to work hard and improve personal abilities to help improve the efficiency of manufacturing. This made a great contribution to the establishment of the company's positive image (professional competitive)in the intense market competition. .
FAQ
Q: Are you a manufacture or trade company?
A: We are manufacture..
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q:What is your package ways?
A:Standard export wooden pallet.We can also pack according to customer's requirement.
Q:What is your delivery time?
A: Normally it is 15 days,but It also depends on the order quantity.
A: We are manufacture..
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q:What is your package ways?
A:Standard export wooden pallet.We can also pack according to customer's requirement.
Q:What is your delivery time?
A: Normally it is 15 days,but It also depends on the order quantity.
