Professional Supply Sturdy Building Materials Roofing Construction Galvalume Steel Coil with SNI Certificate

Product Overview

Description

Professional Supply Sturdy Building Materials Roofing Construction Galvalume Steel Coil with SNI Certificate

Contents	Prepainted Galvanized-PPGI	Prepainted Galvalume-PPGL
BASE METAL	GALVANIZED	GALVALUME / ALUZINC
STANDARDS	JIS G -3312,ASTM A -755 ,	ASTM A 755M,
	EN -10169, IS -14246,G300-G550	WITH SUBSTRATE ASTM A792 M
THICKNESS	0.16~1.20 mm	0.16~1.20 mm
Width	600 TO 1300 mm	600 TO 1300 mm
Coil ID	508 & 610 mm	508 & 610 mm
Coil  OD	1700 mm max	1700 mm max
Coil WT	3 TO 8 MT	3 TO 8 MT Max – With ref. to width of coil
Substrate	Soft, Medium, Hard	Soft, Medium, Hard
Hardness
YS (Mpa)	240 -700	240 -700
Coating Mass	Z 40-275 (Grams / m2)	AZ 50-150 (Grams / m2)
Paint Systems	Primers: Epoxy, PU	Primers: Epoxy, PU
	Polyester (RMP/PE)	Polyester (RMP/PE)
	Silicon Modified Polyester (SMP)	Silicon Modified Polyester (SMP)
	Poly Vinyl Di Flouride (PVDF)	Poly Vinyl Di Flouride (PVDF)
	Back Coating: Epoxy, Polyester, PU	Back Coating: Epoxy, Polyester, PU
Coating	20 – 50 Microns	20 – 50 Microns
Thickness	top can 3 coats and back can 2 coats	top can 3 coats and back can 2 coats
Colour	As Per RAL Chart/Customer requirements.	As Per RAL Chart/Customer requirements.
Surface Finishes	Glossy and Matte	Glossy and Matte
Cut to length	200mm-5000mm	200mm-5000mm
Slits	30mm and above	30mm and above
Packing	Sea Worthy Export Packaging	Sea Worthy Export Packaging

Roofing Construction Galvalume Steel Coil

















Color Coated Coil:

Color coated steel sheet steel coil(PPGI PPGL) has light qualitative, beautiful with good anti-corrosion performance, can direct processing again, color is divided commonly for white, blue, red. It is mainly used in advertising industry, building construction industry, household appliance industry, electric appliance industry, furniture industry and transportation industry. Color coated steel coil uses coating to choose proper resin according to different use environment, if polyester silicon modifies polyester, polyvinyl chloride plastic sol, get together vinylidene chloride to wait. Users can choose according to the purpose.
