29.4V4A lithium battery charger 29.4V4A European TUV CE certification 29.4V4A lithium battery charger

Product Overview

Description

Product name	29.4V4A lithium battery charger 29.4V4A European TUV CE certification 29.4V4A lithium battery charger
Output Power	117.6W
Output	29.4V 4A
Input	100-240V~50/60Hz
Color	Black
Size	154*60*36mm
Weight	450g
Warranty	3 years
Package	PE bag+ White box+ Carton
Usage	Electric vehicle, Ebike, Electric Scooter, Mortor, Golf car, car jumper
Certificate	CCC, UL, cUL, CE, GS, PSE, SAA, RCM, KC, KCC, CB TUV ROHS, BS

Application

♦ Electric vehicle, Ebike, Electric Scooter, Mortor, Golf car, car jumper

♦ Solar Systems, Home Application, UPS

♦ LED Torch, headlight, Portable power bank, etc.



Electrical Specification

♦ Universal Input: 100 – 240V AC, 50/60Hz

♦ Input Plug: EU US UK AU South Korea South Africa Power cords

♦ Output Voltage Range of main products: 4.2~60V DC (Optional)

♦ Output Current Range of main products: 0.5-100A (Optional)



♦ Output: 12.6V 4A

♦ Charge mode: CC--CV (Li-ion battery charger)



All Chargers for lithium ion battery pack
4.2V for 1S 3.7V lithium ion battey pack
8.4V for 2S 7.4V lithium ion battery pack
12.6V for 3S 11.1V lithium ion battery pack
16.8V for 4S 14.8V lithium ion battery pack
21V for 5S 18V lithium ion battery pack
25.2V for 6S 22.2V lithium ion battery pack
29.4V for 8S 24V lithium ion battery pack
42V for 10S 36V lithium ion battery pack
54.6V for 13S 48V lithium ion battery pack
67.2V for 16S 60V lithium ion battery pack
84V for 20S 72V lithium ion battery pack



♦ Led display: Red--in charging; Green--fully Charge

♦ Cut-off Current: 10-15% of Charge current

♦ Output Connector: 3pin Aviation Plugs, XLR socket, DC Jack, Alligator Clips, SAE connector, Anderson Plugs, RCA

♦ Ripple & Noise: 1% of Output Voltage







Safety Certification

♦ CCC

♦ KC

♦ PSE

♦ SAA, C-Tick

♦ UL /cUL. FCC

♦ CE. CB. GS.



Energy Standard

♦ MEPS

♦ CEC-V

♦ ERP V

♦ Energy Star: Level 6

♦ Standby Power: <0.3W



Protection Function

♦ Over voltage protection

♦ Over current protection

♦ Over-load protection

♦ Short circuit protection



Environmental Protection

♦ RoHS, REACH, CPSIA or PAHs Compliant On Request



Operation And Storage Condition

♦ Operation Temperature: -20°C to 40°C

♦ Operation Humidity: 20% to 90% R.H

♦ Storage Temperature: -20°C to 75°C

♦ Storage Humidity: 1% to 90% R.H.

♦ MBFT: > 50,000Hours
