SV 5Q Portable Automobile Multi Exhaust Gas Analyzer Car Exhaust Gas Analyzer

Product Overview

Description

Main Feature of SV-5Q Portable Automobile Multi Exhaust Gas Analyzer

1. SV-5Q Portable Automobile Multi Exhaust Gas Analyzer is a new multi 5 gas analyzer which developed from four gas analyser, it equipped with large-screen LCD display English menu;

2. Used to measure vehicle engine flue exhaust gas CO, HC, CO2, O2, NOx concentration and λ values and COcor

3. Idle with a single, dual idle speed, general-purpose measurement function

4. Measurable by gasoline, LPG, CNG, and alcohol-fueled vehicles

5. National standard and the United States under the new BAR-97 standards for research and development,1-level precision

6. With auto-zero, automatic cleaning, automatic temperature compensation, pressure compensation

7. With the HC residual measurement, traffic monitoring, gas path leakage inspection

8. With rotational speed, oil temperature measurement channels, built-in printer (analog) interface for the choice

9. License plate number can be entered, and 2000 sets of data storage, for future reference function, the clock display

Technical Specification of SV-5Q Portable Automobile Multi Exhaust Gas Analyzer

Measurement Range	CO	0~10×10-2 (%)vol
	CO2	0~20×10-2 (%)vol
	HC	0~10000×10-6 (ppm)vol
	O2	0~25×10-2 (%)vol
	NO	0~40000×10-6 (ppm)vol
Indication Error		Absolute error		Relative error
	CO	±0.06×10-2(%)vol		±5%
	CO2	±0.5×10-2(%)vol		±5%
	HC	±12×10-6 vol		±5%
	O2	±0.1×10-2(%)vol		±5%
	NO	±25×10-6 vol		±4%
Preheating Time	10 min.(3 min. warm-up for fast measurement)
Environmental condition	Temperature		-5~40 centigrade
	Humidity		no more than 85%
	Atmospheric pressure		86~106kPa
	Power		AC 220V±10%; 50 Hz±1Hz
Gross Weight	9.8kg
Packing Size	420*320*250(mm)
