Vacuum pressure impregnation plant is mainly used for impregnate the motor coils with insulating coating . Under the circumstance of vacuum pressure,  motor coil is dehydrated and degassed to reduce the impact of water and air on insulation. And in the  impregnation stage, the inner and outer structure is permeated by insulating varnish to upgrade insulation and to improve overall electrical performance.

The purpose of vacuum impregnation is to improve the moisture resistance, heat resistance, electrical conductivity, magnetic conductivity and mechanical properties of coil winding or iron core. The basic requirements of the treatment are that the coil or core is impregnated, filled, glued and formed a tough and elastic coating on its outer surface. Vacuum impregnation equipment is a kind of equipment that coats the paint on the surface of coil or core and penetrates into the internal cracks in the vacuum state. Compared with the general impregnation technology, its main advantages are uniform and compact film, firm adhesion, and better insulation performance of treated coils.

Vacuum impregnation process is a key link in the production of products. The quality and production efficiency of products are directly affected by the quality of production control.

This equipment is suitable for impregnation treatment of new energy motor and H-class dry-type transformer,suitable for motor impregnated with Dupont NOMEX insulating paper. The motor with German MORA technology can also meet the production needs.

2.Schematic diagram

Put the product into the impregnation tank →Vacuum the impregnation tank →Maintain vacuum →Enter the paint into the impregnation tank→Vacuum again →Maintain vacuum →Vacuum relief →Return the paint →Dropping the paint →Open the lid to take the product out
