The serial drycleaning machines are applied to drycleaning for clothes of cotton, wool, felt, polyester (except of spandex artificial leather or pleuche), wool blanket and down.
The drycleaning equipment can make washing, extracting and dryingas well as distillation done in one unit. It uses perchloroethylene(perc) as solvent, which can remove grease off the clothes, and no hazard of fire.
The clothes drycleaned with the equipment are clean, soft, smooth, and easy finishing, without shrinkage or color fading.
Cyclical filtering device can make solvent clean during running so that good quality of drycleaning is obtained.
Description
unit
GXZQ-8
GXZQ-12
GXZQ-22
Capacity(dry load)
kg
8
12
22
Inner drum
mm
650*479
810*475
940*640
Washing/extraction motor power
kW
0.4/1.5
0.55/1.8
3
Filter motor power
kW
0.55
0.55
0.55
Pump motor power
kW
0.75
0.75
0.75
Fan motor power
kW
0.75
1.1
1.5
Distillation motor power(electric heating)
kW
0.75
6
13.5
Drying motor power(electric heating)
kW
0.75
9
13.8
Refrigeration compressor
kW
1.5
2.6
3.8
Washing/extraction motor speed
rpm
40/400
40/400
40/400
Steam pressure
Mpa
0.4-0.5
0.4-0.5
0.4-0.5
Cooling water pressure
Mpa
0.2-0.3
0.2-0.3
0.2-0.3
Compressed air pressure
Mpa
0.5-0.7
0.5-0.7
0.5-0.7
Solvent
PERC
PERC
PERC
Dimension
mm
1680*1000*1890
1650*1160*2120
1620*1970*2320
Weight
kg
790
2300
2300
