Product Description
Features
Simple But Practical Onboard Software
NTS-332R4offers the quick response and clear feedback for its onboard software, like data input, measurement, stake out and roads.
Higher Efficiency with Auto Height
NTS-332R4 is available to add the function of Auto Height on its laser plummet. Free your hands by automatically measurement for instrument height (±2mm) to avoid the extra mistakes by manual. Auto height will increase the efficiency by its simple steps.
Stable Performance Under Low Temperature
NTS-332R4, the modified model concentrated on operation and test under low-temperature -35℃. It’s an economical choice that keep the high accuracy in extremely tough conditions.
Distance measurement
|
|
The maximum distance (Good weather)
|
Single prism
|
5.0KM
|
|
|
Figures show
|
Maximum:999999.999 Least:1MM
|
Accuracy
|
2+2PPM
|
Measurement time
|
Precision measurement 3S, Track 1S
|
Meteorological correction
|
Manual input ,auto correction
|
Prism constant correction
|
Manual input,auto correction
|
Angle measurement
|
A goniometer
|
Photoelectric incremental
|
Code disc diameter
|
79MM
|
Minimum reading
|
1"/5"Optional
|
Accuracy
|
2"
|
Detection method
|
Level disk:Of radial Caine straight plate:Of radial
|
Telescope
|
Imaging
|
Erect
|
Tube length
|
154MM
|
Lens effective aperture
|
45MM EDM:50MM
|
Magnification
|
30*
|
Field of view
|
1Degree30Second
|
Resolution
|
3"
|
Minimum focusing distance
|
1M
|
Automatic vertical compensator
|
System
|
Dual axis liquid electric
|
Scope of work
|
+/-6'
|
Accuracy
|
1"
|
Spirit level
|
Vial
|
30"/2MM
|
Circular level
|
8'/2MM
|
Laser plummet
|
The Laser precision :+/-M
|
Optical Plummet
|
Imaging
|
Erect
|
Magnification
|
3*
|
Adjustment range
|
0.3M To infinity
|
Field of view
|
5 degree
|
Display section
|
Type
|
Dual-side
|
Mechanical battery
|
Power supply
|
Rechargeable nickel-Metal hydride batteries
|
Voltage
|
DC6V
|
Continuous working time
|
8Hour
|
Size and weight
|
Size
|
206*180*353MM
|
Weight
|
5.4Kg
|

|
