OEM BK7/K9, Fused Silica, CaF2 Plano Convex/Plano Concave Cylindrical Lenses
- Category: >>>
- Supplier: Wuhan Especial Optic Inc.
Share on (62556684296):
Product Overview
Description
Product Description
A cylindrical lens is demonstrated using two planar substrates and a homogeneous liquid crystal (LC) layer. The top substrate has slit electrodes on its outer surface and the bottom has a transparent electrode on its inner surface. An applied voltage across the cell induces a cylindrical-like gradient refractive index
within the LC layer which causes light to focus. The focal length is tunable by the applied voltage. Such a cylindrical lens can be easily fabricated with wide aperture size.
Material | BK7 or Fused Silica or optical glass |
Design Wavelength | 632.8 nm |
Dimmensions(Square or Circle) | 1 to 300mm |
Surface Figure | x: λ/2; y: 2λ |
Diameter Tolerance | +0.00, -0.025 mm |
Thickness Tolerance | ±0.1 mm |
Focal Length | ±1% |
Centration | <3 arc minutes |
Clear Aperture | >90% |
Surface Quality | 60/40 or 40/20 scratch and dig |
Protective Bevel | 0.25 mm x 45° |
Detailed Images
