semi automatic cleaning KSG 1.5A series mobile high vacuum dust collector with intelligent PLC
- Category: >>>
- Supplier: Shanghai Kaisen Environmental Technology Co. Ltd.
Share on (62558678797):
Product Overview
Description
semi-automatic cleaning KSG-1.5A series mobile high vacuum dust collector with intelligent PLC
Product introduction
Mobile high vacuum fume & dust extractor is an air purification machine with advanced technology and craftsmanship, researched and developed independently by our company based on the specific conditions of welding, cutting and polishing workshops. It can be easily operated with high air flow, low noise, stable performance. When welding begin, turn on /off through the automatic / manual operation; in addition, high / low speed can be setted and easy to use. The corresponding indicator on the control panel will also light up to make indication.
The extractor has front connector and can be connected to various professional suction connectors, suction welding guns or breathing masks through a hose of Φ44(51)mm; by connecting with hose of Φ44(51)mm and professional nozzle, it also can be used in robot and welding machine’s fume purification. The nozzle is fixed on the welding gun and moves with the welding gun to suck welding smoke simultaneously; also be used in the welding test and in the cleaning of the training sites.
The extractor can be connected to all kinds of magnetic sucker’s nozzle through the hose, or be connected to 1-2 pieces of high vacuum suction welding guns.
On the control panel, it includes:
- Power Switch
- Fan Switch
- Power indicating light
- Semi-automatic cleaning
Working principle
The fume extractor has two stages filtering, first stage filtering is filtered of large particle spark, second stage is filtered of tiny dust.
This extractor is the preferred equipment for industry processing, welding, cutting and grinding dust disposal etc.
Main advantages
1. It is suitable for the welding occassion of frequently changing.
2. Professional solving the robot welding fume issue with the special suction nozzule.
3. DN51 or DN44 mm hose is available, it is easy to move and install in the process of using.
4. High efficiency vacuum pressure fan makes sure the usage life and suction force & air flow.
5. There is smart full automatically cleaning type with 2-3 suction nozzules model for optional.
6. The power is available from 1.1kw to 20 Kw (1.1,1.5,2.2,3.3,3.4,5.5/7.5/9/11/13/20 Kw), it will different
requirements.
7. The structure of design is reasonable, the size is small and low noise with large suction force .
Parameters
Model | KSG-1.0A | KSG-1.5A | KSG-2.2A |
air flow | 180 (m3/h) | 195 (m3/h) | 372 (m3/h) |
Motor Power | 1.0 (kw) | 1.5 (kw) | 2.2 (kw) |
Voltage | 220V/50 Hz | 3x380V/50 Hz | 3x380V/50 Hz |
Filtering area | 8 (m2) | 8 (m2) | 8 (m2) |
Surface Cleaning Methods | Change filter cartridge | Automatic Cleaning | Automatic Cleaning |
Max Pressure | 16000-25000 (Pa) | 23000-29500 (Pa) | 27000 (Pa) |
Filtration Efficiency | >99.9% | >99.9% | >99.9% |
Dusting interface | 1 pc (φ44 mm) | 1 pc (φ51 mm) | 2 pcs (φ44 mm) |
Noise | ≤72 dB(A) | ≤65 dB(A) | ≤70 dB(A) |
Demission | 580×445×920 (mm) | 550×650×1110 (mm) | 600×695×1200 (mm) |
Weight | 60 ±3(kg) | 107 ±5(kg) | 156 ±5(kg) |
