750W 930 mBar Dty Oil Free Vacuum Pump OLF1500D Lab Dental Medica Oil Free Air Compressor Oil Free Head Rocking Piston Type
- Category: >>>
- Supplier: Zhejiang Shengyuan Compressor Manufacturing Co. Ltd.
Share on (62558719569):
Product Overview
Description
Product Display
Product Parameter
Model# | VCM-1500AFV | VCM-1500AFT | ||
Type | Oil Free Vacuum Pump | Oil Free Vacuum Pump | ||
Rated voltage (V/Hz) | AC~220V/50Hz | AC~220V/50Hz | ||
Rated current (A) | 7.00A | 7.00A | ||
input power(W) | 750W | 750W | ||
Rated speed (RPM) | 1450RPM | 1450RPM | ||
Noise Level dB(A) | 68dB | 68dB | ||
Use ambient temperature (℃) | MIN.-5°C ~ MAX. 40°C | MIN.-5°C ~ MAX. 40°C | ||
vacuum (MBAFR) (Rm) | Rated Pressure | -930 mbar | -980 mbar | |
Restart | 0 | 0 | ||
Compressor Pump Performance (Ltr/m @ mBar) | * 0 mBar | 280.0 Ltr/min | 140.0 Ltr/min | |
*-200mBAR | 154.0 Ltr/min | 77.0 Ltr/min | ||
*-400mBAR | 84.6 Ltr/min | 42.3 Ltr/min | ||
*-600mBAR | 46.6 Ltr/min | 23.3 Ltr/min | ||
*-800mBAR | 25.6 Ltr/min | 12.8 Ltr/min | ||
Motor performance | Wire material | Copper | Copper | |
Stator Size | 170 sheets | 170 sheets | ||
Stator Sheets Material | Silicon Steel | Silicon Steel | ||
Standard Equipment | Thermal Protector | Yes | Yes | |
Inlet & Exhaust Specifications | G1/4 | G1/4 | ||
Size & Weight | Net Weight (Kg) | 19.5KG | 19.5KG | |
Machine Size (mm) | 305x160x288mm | 305x160x288mm | ||
Packaging | HONEYCOMB CARTON | HONEYCOMB CARTON | ||
Gross Weight(Kg) | 20.5KG | 20.5KG | ||
Packaging Dimensions ( mm) | 360x330*322mm | 360x330x322mm | ||
