#373 New TYPE C interface 1A Li ion battery module lithium ion battery charging 2 in 1 type c Lithium battery protection board
- Category: >>>
- Supplier: Shenzhen Hairuixing Technology Co. Ltd.
Share on (62560363653):
Product Overview
Description
ODM/OEM services offered! Welcome to inquire me for more details!
Product Description
#373 New TYPE-C interface 1A Li-ion battery module lithium ion battery charging 2 in 1 type c Lithium battery protection board
Module features and parameters:
Input with TYPE C USB socket
You can directly use the mobile phone charger as input to charge the lithium battery,
And still retain the input voltage wiring solder joints, which can be very convenient DIY
| Input voltage: 5V Charging cut-off voltage: 4.2V ± 1% Maximum charging current: 1000mA Battery over-discharge protection voltage: 2.5V Battery overcurrent protection current: 3A Board size: 2.6 * 1.7CM |
Instructions:
Note: When the battery is connected for the first time, there may be no voltage output between OUT + and OUT-. At this time, connect the 5V voltage and charge it to activate the protection circuit.
If the battery is opened shortly from B + B- and then connected A charge is required to activate the protection circuit. When using a mobile phone charger as input, please note that the charger must be able to output 1A or above, otherwise it may not charge normally Connect the battery to B + B-, insert the mobile phone charger to the USB socket, the red light is charging, and the blue light is full. |
