3. Surface Temperature: 80°C~300°C , the temperature tolerance less than ±5°C 4. Lead wire spec: AWG24, length:180mm Adjustable
5. Certifications: UL,CQC,RoHS,Reach.
Note:
The lead wire, fiber glass sleeve, insulate film and shells can customized.
Main Features
a. High heating efficiency.
b. Low electricity consumption : High temperature with low current.
c. Self-regulating for temperature, safty & long life.
d. Low noise level.
e. Wide application area.
Ptc heating element available specifications
JK Molde
PTC size
Voltage(V)
Temperature(℃)
Power(W)
JK-CPTC-F-01
17*10*3.0mm
24-240V
60℃-305℃
10W-100W
JK-CPTC-F-02
35*6*3.2mm
12-240V
60℃-305℃
10W- 100W
JK-CPTC-F-03
35*8*3.2mm
12-240V
60℃-305℃
10W- 100W
JK-CPTC-F-04
35*13*3.6mm
12-240V
60℃-305℃
10W- 100W
JK-CPTC-F-05
48*8*3.0mm
12-240V
60℃-305℃
20W- 200W
JK-CPTC-F-06
48*10*3.0mm
12-240V
60℃-305℃
20W- 200W
JK-CPTC-F-07
48*13*3.0mm
12-240V
60℃-305℃
20W- 200W
JK-CPTC-F-08
48*15*3.0mm
12-240V
60℃-305℃
20W- 200W
JK-CPTC-F-09
60*10*3.2mm
12-240V
60℃-305℃
20W- 200W
JK-CPTC-F-10
60*13*3.75mm
12-240V
60℃-305℃
20W- 200W
JK-CPTC-F-11
64*12*3.0mm
12-240V
60℃-305℃
20W- 200W
JK-CPTC-F-12
70*6*3.25mm
12-240V
60℃-305℃
20W- 300W
JK-CPTC-F-13
70*10*3.2mm
12-240V
60℃-305℃
20W- 300W
JK-CPTC-F-14
70*13*3.2mm
12-240V
60℃-305℃
20W- 300W
JK-CPTC-F-15
70*15*3.2mm
12-240V
60℃-305℃
20W- 300W
JK-CPTC-F-16
72*10*3.3mm
12-240V
60℃-305℃
20W- 300W
JK-CPTC-F-17
72*13*3.25mm
12-240V
60℃-305℃
20W- 300W
JK-CPTC-F-18
72*15*3.25mm
12-240V
60℃-305℃
20W- 300W
JK-CPTC-F-19
83*15*3.25mm
12-240V
60℃-305℃
30W-350W
JK-CPTC-F-20
90*10*3.25mm
12-240V
60℃-305℃
30W-350W
JK-CPTC-F-21
96*15*3.25mm
110-240V
60℃-305℃
30W-350W
Product Quality certification
UL & TUV & SA & CQC
ISO/TS16949:2009
ISO9001:2008
ROHS & REACH
Ptc heating element workshop
Ptc heating element other Main Applications
Notice in application
1)After switching on, the power is large, and then decrease, finally it become steady state. The steady state power changes with applied conditions. Faster is the heat conduction, higher is the steady state power; higher is the surface temperature, higher is the power.
2)The surface temperature of this kind Ptc heating element can be controlled by itself, control circuit may be omitted in most appliances. 3)Our PTC products are high reliable, long lifetime, but if they are assembled improperly, the power or temperature may be instable. 4)Parallel connection is necessary for two or more Ptc ceramic heater for coffee maker connection
Our main customer
Packaging & Shipping
Standard packing: Plastic bag + foam plates + Cartons
Carton size: 40cm * 22cm *19cm
Our Services
Quick response: Your inquiries and quotation will be replied in 24hours
Sample support: 3 free samples are available in 3~5days.
ETD: Your orders will be finished in 3-15days, depends on quantity.
Payment term: T/T, L/C, D/P,D/A, Western Union & Paypel (samples only)
Company Information
Shenzhen Jinke Special Materials Co.,Ltd was founded in 1987. We are the first & biggest PTC heating element manufacturer in China and an high technology enterprise of R&D, production & sales. Our company have the ISO9001:2008, ISO9001:14001, and TS16949 certifications.
Our main products include PTC heating element, PPTC resettable fuse, ceramic fan heaters, coolers, humidifiers, graphites, and carbon nanotubes. All the products have been approved by UL,ROHS,CE certifications. OEM & ODM are welcome!
