Factory in stock 10 16 20 25 40 50 63 100 Ton Mechanical Press Machine Power,iron steel plate hole power press machine

Product Overview

Description

Factory in stock 10 16 20 25 40 50 63 100 Ton Mechanical Press Machine Power,iron steel plate hole power press machine



Product Description



J23 series open press is a sheet metal Universal presses for shearing, punching,

blanking, bending and shallow drawing work. Usually used for ( communications,

computers, household appliances, furniture, vehicles, (cars, motorcycles, bicycles)

metal parts stamping and forming).



Technical parameter

NO	Name	J23-16T
1	Nominal force(KN)	160
2	Nominal force stroke(mm)	2
3	Slider stroke(mm)	60
4	Slider stroke times(time\\min)	120
5	Maximum height for die loading	210
6	Adjustment range for die loading height	40
7	Distance between slider center line and the fuselage	120
8	Worktable size	290*460
9	Work table blanking hole size	D125*110*220
10	Slider bottom size	150*170
11	Shank hole size	D35*Depth60
12	Distance between columns(mm)	210
13	Bolster thickness(mm)	40
14	Tilting degree(degree)	25
15	Motor(kw)	1.5





Main feature

1, With foundry structure for better vibration resistance.

2, Adopt horizontally placed crankshaft, external gear is open and easy for maintenance.

3, The good rigidity of Casting box structure slider

4, Built-in block collapsed overload protection device, the structure is simple, if slider after

overload, fuse collapsed destroyed to protect the machine and mold from damage

5, Four elongated triangular rail, easy for adjustment.

6, Adopts hands and foot switch operation buttons design, it’s easy to activate continuous,

single and adjustment practices.

7, Compatible with the corresponding punch automatic feeding system, which having a feeding



error detection, pre-cut and pre-breaking device, low cost and high efficiency.

Detailed image









J21 Type







Our service



Pre-sales Service

1. Inquiry and consulting support

2. Sample testing support

3. Recommend the most suitable machine according to customer's purpose



4. Factory visiting welcomed



After-sales Service

1. Training how to install the machine

2. Training how to use the machine

3. Warranty 1 year



4. Engineers available to service machinery oversea
