Cnc fiber laser cutter sheet metal





Characteristics:1. Product description:

*Motor and drive is Japan Yaskawa,linear guide rail is Taiwan Hiwin

*Electrical control system adopts international famous brand:Schneider and OMRON ect.

*The guide rail and rack are calibrated by precision collimating instrument, and the precision is achieved±0.03mm.

*Using the Japanese smc intelligent gas group design, can automatically adjust pressure, automatic ventilation, pressure detection

*The whole machine is tempered at high temperature, the internal stress is eliminated with the furnace cooling,

and the imported gantry milling finishing, ensure normal use of 20 years without deformation.

*Double exchange platform saves time of loading and unloading

Application fields:

*It can be used for cutting various kinds of metal plates and tubes, mainly for stainless steel, carbon steel,

manganese steel, galvanized sheet, various alloy plates and rare metals.

*widely used in machinery manufacturing,steel structural,mining machinery,

metal cabinets manufacturing,ventilation and refrigeration and elevator manufacturing,

lighting advertising and sign-making,auto parts,etc.



Cutting plate size	1500*3000mm
X axis travel	1500mm
Y axis travel	3000mm
Z axis travel	120mm
Position accuracy	±0.03mm
Repeat position accuracy	±0.03mm
Maximum feed speed	120m/min
Z axis height control	CNC,servo
Z axis servo system	Capacitive height sensor
Power	500W
Weight	4000kg
Maximum load of worktable	1500kg
Cutting thickness (in the case of cutting conditions)	carbon steel 0.5-10mm,stainless steel 0.5-5mm



Machine tool configuration brand

The  accessories we recommend are of relatively high quality,different brands of accessories corresponding to different prices,

you can specify the configuration manufacturer.

CNC system for laser cutting	CypCut
Y shaft motor and drive	Japan Yaskawa  1.8KW
X shaft motor and drive	Japan Yaskawa 0.85KW
Fiber laser	IPG/Raycus/MAX/can be designated by the customer
Z axis precision ball screw	Taiwan Hiwin H level accuracy
X axis/Y axis/Z axis precision linear guide rail	Taiwan Hiwin H level accuracy
X axis /Y axis precision gear rack	Taiwan YYC   Grinding   din6 grade accuracy
X axis /Y axis precision reducer	Taiwan  shimpo    3 arc minute   Flange connection
Precise pressure regulating valve, high and low pressure pipe joint, high and low pressure pipeline, etc.	Japan SMC,US PARKER etc.
Collimating mirror	Germany LT
Automatic programming software	CypCut
Electrical control system of machine tools	SIEMENS, Schneider etc.
Water cooler	Baichao original
Laser head	Switzerland Raytools
Computer	Industrial Personal Computer  Memory 4G/ hard disk 120G
