Hot selling Japan brand Small Concrete Mixer Truck with 8 cubic meters capacity
- Category: >>>
- Supplier: Oriemac Machinery & Equipment (Shanghai) Co. Ltd.
Share on (62566728116):
Product Overview
Description
6x4 lsuzu 8M3 Mixer Truck
Product Description
lSUZU 350HP 6x4 8m3 Concrete Mixer Truck
1. Chassis model: QL1250
2. Drive Type: 6x4, LHD with AC
3. Curb mass: 13700kg
4. Wheelbase: 3985+1370mm
5. Engine model: 6UZ1-TCG51
6. Emission standard: Euro 5
7. Tire specifications: 12R22.5
8. With 8 forward gear and one reverse gear
WhatsApp: +8618217305485
WeChat: 18217305485
www.oriemac.com
Specs Chart
| Chassis model | QL1250 |
| Cab | ISU-ZU VC61 Cab ,single row with one berth,Central lock,power windows |
| Drive position | Left hand drive ,Air condition |
| Over Dimensions(L×W×H)(mm) | 9800×2500×3930 |
| Curb mass(kg) | 13700 |
| Wheelbase(mm) | 3985+1370 |
| Drive style | 6x4 |
| Tread(front/rear)(mm) | 2065/1855/1855 |
| Approach/Departure angle(°) | 17/17 |
| Air condition | Yes |
| Leaf-spring system | 8/10 |
| Maximum speed (km/h) | 80 |
| Engine model | 6UZ1-TCG51 |
| Manufacturer | Qingling ISU-ZU (Chongqing) Engine Co.,Ltd |
| Displacement(ml)/Power(HP) | 9839/350 |
| Emission standard | Euro 5 |
| Fuel type | Diesel |
| Fast brand , 8 forward gear and 1 reverse gear | |
| Tire specifications | 12R22.5 |
| Number of tyres | 10+1 Spare tire |
| Front axle | 7ton |
| Rear axle | 18ton,double axle |
| Volume of mixer | 8m3 |
| Hydraulic pump | Ea-ton brand |
| Hydraulic motor | Ea-ton brand |
| Reducer | BONFI-GLIOLI brand |
| Rotating speed | 6-12r/min |
| Feed rate(m3/min) | ≥3 |
| Discharge(m3/min) | ≥2 |
| Discharge residual percentage | ≤0.7 |
| Type of water supply | Air pressure |
Product photos
