Best price solar panel el tester china solar sun tester pv solar cell tester
Product Description
MODEL
OSMT-A
OSMT-B
Lamp spectrum
In line with iec60904-9
spectral Irradiance distribution requirement(AM1.5)
Light intensity
700-1200W/Mm2continuous adjustable range
Light intensity non-uniformity
≤±2% [A]
≤±3%
Light intensity instability degree of
irradiation(STI)
≤±0.5% [A]
≤±2% [A]
Light intensity instability degree of
irradiation(LTI)
≤±2%
≤±2%
Test results consistency
≤±0.5%[A]
≤±1%
Single flash time
10ms
10ms
Effective test range
200×200mm
/0.1W-5W
Measuring voltage
0-0.8V(resolution 1mV)
Measuring current
0-20A(resolution 1mA)
Test parameters
Isc,Voc,Pmax,Vm,Im
FF,EFF,Temp,Rs,Rsh
Power supply
AC220V/50HZ/2KVA
Air supply
0.5-0.8Mpa
Weight
400KGS
450KGS
l Key components use import abroadbrand
l A gradespectrum
l A grade unevenness degree ofirradiance
l four-line measurement,14-bit 4-channel high-speed synchronous acquisitioncard
l 10 parameters display and Measurement Parameter displays in Tabulation and Graphicway
l Pneumatic and bufferingcontact
l Temperature automaticallycompensating
l Voice counts off and prompts, Counting prompt of flashtimes
l 24 continuouswork
l Import XenonLamp.
