Nexus 3524 XL 24 SFP ports Enhanced Extended Memory

N3K Switch Module N3K-C3524P-XL Gigabit Network Ethernet switch

Product Code

N3K-C3524P-XL

Physical

· 24 fixed SFP+ ports (1 or 10 Gbps); expandable to 48 ports

· Dual redundant hot-swappable power supplies

· Four individual redundant hot-swappable fans

· One 1-PPS timing port, with the RF1.0/2.3 QuickConnect connector type

· One 10/100/1000-Mbps management port

· One RS-232 serial console port

· Two USB ports

· Locator LED

· Locator LED button

Performance

· 480-Gbps switching capacity

· Forwarding rate of 360 mpps

· Line-rate traffic throughput (both Layer 2 and 3) on all ports

· Configurable MTUs of up to 9216 bytes (jumbo frames)

Physical dimensions

1.72 x 17.3 x 18.38 in. (4.36 x 43.9 x 46.7 cm)

Weight

17.4 lb (7.9 kg)
