Delivery time If the products you ordered are in stock, we can ship them within 7 days after receiving your payment. If the products are custom made or out of stock, within 24 tons, it is need 20-35 days to produce after confirmed every details.
Features
*Not easy to loose, solid and strong.
* The special expansion part and anchoring force is stronger.
*Environmental zinc layer is more consistent with environment.
*Widely recognized expansive parts in the world.
Application Area Suitable for concrete and dense natural stone, metal structures, metal profiles, floor plates, support plates, brackets, railings,windows, curtain walls, machines, beams, beams, brackets, etc.
Qianmu Fastenter Manufacturing Company's ISO9001 Certificate of Quality
Specification
ANSI Standard Specification
Thread
Drill Hole
(mm)
Length Range
(mm)
Design Drawing
Force(KN)
Ultimate Drawing
Force(KN)
Design Shear
Force(KN)
Ultimate Shear
Force(KN)
(mm)
(mm)
Force(KN)
Force(KN)
Force(KN)
Force(KN)
1/4
1/4(6.35mm)
≈45-120
5
9.7
--
--
5/16
5/16(8mm)
≈50-145
8
16
6
9
3/8
3/8(10mm)
≈60-200
12
24
8
14
1/2
1/2(12.7mm)
≈70-305
18
33
18
29
5/8
5/8(16mm)
≈80-305
22
51.8
26
45
3/4
3/4(19.5mm)
≈95-305
35
70
31
62
1
1(25.4mm)
≈125-405
50
113
45
88
Packing & Delivery
By default, our company uses the ordinary packaging, that is corrugated carton and white box. there are no any other words except the specifications and quantities on the packaging. if you have special need, we can customize the packaging mark for you. and we can provide fumigated pallets.
Company Profie
Hebei Qianmu Fastener Manufacturing Limited Company was founded in 2017, the registered capital is 3 million. Our factory locates in YongNian China, research and development, sales in one integrated manufacturing comprehensive enterprise. Since the beginning of this century, the company has been engaged in fastener manufacturing industry, and has won widespread favor and approval registered "Hebei Qianmu Fastener Manufacturing Co., Ltd." in 2017, With many years of production and manufacturing experience, with its own galvanized factory and production factory, The implementation of multi-links strictly control, ensure the excellent quality, The annual output can be 10000 tons, ensure timely delivery. Now our main products include Wedge Anchor, Sleeve Anchor, Chemical anchor, Wood Screw, Drop in Anchor, 3/4 Fix Bolt, thread rod, nut, washer, bolt, etc.
FAQ
Q: How about the quality of your product? A: 100% inspection during production. Our products are certified to ISO9001, international quality standards. Q: What material of the product can you supply? A: Carbon Steel, can according to your requirement. Q: What's the delivery time? A: For products in stock, we can ship it within 7 days after receiving your payment. For custom order, within 24 tons, production time is 20-35 days after confirmed every details.
