DC braking inverter triple phase 15kw 18.5kw 22kw economical variable frequency drivefactory VFD AC drive
- Category: >>>
- Supplier: Suzhou Vaidnor Electric Technology Co. Ltd.
Share on (62570068955):
Product Overview
Description
Product Parameters
710 series A D V A N T A G E
The series of VDF710 is based on the market demand of small power ,small volume and simple speed regulation, the single-phase 220V AC and three-phase 380V AC smart inverter are introduced. As a small volume inverter, VDF710 series has high power density, high EMC design specifications, high protection performance and other significant advantages, can be widely used in wood sculpture, glass edge grinding, medical centrifuges, automation production lines, electronic equipment, logistics equipment, spindle small
automatic machines
automatic machines
Items | Specifications | ||||||
Input | Rated voltage, frequency | 380V/220V;50/60Hz | |||||
Permissible range of operating voltage | Fluctuation:<＋20%; voltage imbalance rate:<3%; freq fluctuation:<＋5% | ||||||
Output | Voltage | 0~380V/0~220V | |||||
Freq | 0.0~630.0Hz | ||||||
Overloading ability | 150% rated current 1min; 200% rated current 1s; 220% rated current, instantaneous trip. | ||||||
Main control performances and featured functions | Control mode | V/F control(simplified magnetic flux control technology)/advanced magnetic flux vector control | |||||
Modulation mode | Flexible PWM technology | ||||||
Speed range | 1:50 | ||||||
Startup torque | At 3.0Hz,>150% rated torque(VF control),torque response time <50mS At 1.5Hz,>180% rated torque(Advanced magnetic flux vector control),torque response time <20mS | ||||||
Freq accuracy | Digital setting: maxi freq ×＋0.02%; analog setting maxi freq×＋0.1% | ||||||
Freq resolution(step) | Digital setting:0.1 Hz, analog setting: maxi freq × 0.05% | ||||||
Torque boost | Automatically arise torque/ arise torque by hand 0.1%~30.0% | ||||||
V/F curve | 21 modes: linear, 2 squared characteristic curve and V/F curve with multiple dots | ||||||
Speed up/down curve | Linear curve speed up/down: 2 kinds of speed up/down time, longest time: 1 hour | ||||||
DC braking | Startup freq of DC braking:0.00Hz~maxi freq, Braking time:0.0s~30.0s, braking current: 0.0~150.0% rated current of motor | ||||||
Auto voltage regulation(AVR) | When system voltage change, able to keep output voltage constant automatically | ||||||
Compensation of rotation error | Rational setting of compensation for rotation error, can compensate the change of rotation speed due to load, to achieve higher control accuracy of speed | ||||||
Limit the operation current, prevent frequently tripping due to over-current | |||||||
Control of over-voltage speed loss | Limit the operation voltage, prevent frequently tripping due to over-voltage | ||||||
Magnetic flux braking | To achieve shorter speed-down/braking time through this mode | ||||||
Over-modulation | Utilize over-modulation technology for over the basic freq, to get higher voltage output, increase hi-freq output torque of the motor. | ||||||
No stop at instantaneous | When voltage fall down at short time, it can keep inverter busbar voltage constant, to avoid tripping. | ||||||
