Customized primary furnace hvac aluminium cardboard filter merv 13 frame panel pleated air pre filter activated carbon filter
- Category: >>>
- Supplier: Guangzhou Jielv Environment Technology Co. Ltd.
Share on (62570716831):
Product Overview
Description
Product Description
The Pleated Panel Pre Air Filters are available in many standard sizes, and we can also customise to any size you require. The filter material mainly has non-woven fabric, active carbon, synthetic fiber and fiberglass, which have the characteristics of low initial resistance and large volume of dust.
Also the filter frame can be replaced with cardboard frame, galvanized frame, stainless steel or aluminum alloy frame to reduce the purchase cost.
Name | Pleated Panel Pre Air Filters |
Material | High quality polyester synthetic fiber or cotton fiber mixed with non-woven filter material |
External Frame | Cardboard, aluminum alloy or galvanized steel |
Inner Frame | Weld wire mesh, rust protection, spray cast wire mesh |
Efficiency | G3(EN779): Gravimetric efficiency 90~90%; G4(EN779): Gravimetric efficiency ≥90% |
Operating Temperature | ≤70℃ |
Humidity | ≤100%RH |
Resistance | ≤250pa |
Features | 1) Efficiency Rate: G1-G4. 2) Low maintained pressure drop for longer filter life. 3) Choose High-lofted cotton and synthetic media blend. 4) Media and wire formed in radial pleats for high dust loading. 5) High wet-strength beverage board frame creates a rigid and durable enclosure and prevents costly flter blowouts. 6) The default outer frame is cardboard frame (aluminum or other materials can be customized according to customer needs). |
Filter Class (EN799) | Model | W*H*D (mm) | Rated Air Flow (m³/h&≤Pa) | Material Color | ||||
G2 | JL-GP6621 | 595*595*21 | 3200/50 | White | ||||
JL-GP6521 | 495*595*21 | 2700/50 | White | |||||
JL-GP6625 | 595*595*25 | 4000/50 | White | |||||
JL-GP6525 | 495*595*25 | 3200/50 | White | |||||
JL-GP6646 | 595*595*46 | 1500/50 | White | |||||
JL-GP6546 | 495*595*46 | 4000/50 | White | |||||
G3 | JL-G3Z6646 | 595*595*46 | 1700/30; 3400/50 | white | ||||
JL-G3Z6546 | 495*595*46 | 1400/30; 2800/50 | white | |||||
JL-G3Z6346 | 290*595*46 | 1200/30; 1700/50 | white | |||||
JL-G3Z5546 | 495*495*46 | 850/30; 2400/50 | white | |||||
JL-G3Z5446 | 395*495*46 | 900/30; 1800/50 | white | |||||
JL-G3Z5346 | 295*495*46 | 700/30; 1400/50 | white | |||||
G4 | JL-GZZ6646 | 595*595*46 | 1700/35; 3400/50 | Dark green | ||||
JL-GZZ6346 | 290*595*46 | 850/35; 1700/50 | Dark green | |||||
JL-GZZ6546 | 490*595*46 | 1400/35; 2800/50 | Dark green | |||||
JL-GZZ6695 | 595*595*95 | 1700/32; 3400/50 | Dark green | |||||
JL-GZZ6395 | 290*595*95 | 850/32; 1700/50 | Dark green | |||||
JL-GZZ6595 | 490*595*95 | 1400/32; 2800/50 | Dark green | |||||
Please contact us for more size. We not only provide various standard specifications, but also accept customization. | ||||||||
More Advantages:
2) Low maintained pressure drop for longer filter life.
3) Choose High-lofted cotton and synthetic media blend.
4) Media and wire formed in radial pleats for high dust loading.
5) High wet-strength beverage board frame creates a rigid and durable enclosure and prevents costly flter blowouts.
6) The default outer frame is cardboard frame (aluminum or other materials can be customized according to customer needs).
Applications
It is widely used as first stage filters in air condition system, to prevent dust accumulates in the coil, fan and tube of hvac, and to prolong the life of high efficiency filters.
1) Clean rooms ( suitable for use in multilayer filter filtration system or micro component electronic manufacture & assembly).
2) Food processing industry.
3) Pharmaceutical Processing.
4) Aerospace Engineering.
5) Genetic & Biological research.
6) Biohazard Atmosphere.
7) Laminar Flow Workstations.
8) Bio Safe Hoods(Biological Safety Cabinets).
9) Hospital Operating Theaters & Intensive care units.
10) Atomic Research.
11) Electronic, medicament, food.\t
1) Clean rooms ( suitable for use in multilayer filter filtration system or micro component electronic manufacture & assembly).
2) Food processing industry.
3) Pharmaceutical Processing.
4) Aerospace Engineering.
5) Genetic & Biological research.
6) Biohazard Atmosphere.
7) Laminar Flow Workstations.
8) Bio Safe Hoods(Biological Safety Cabinets).
9) Hospital Operating Theaters & Intensive care units.
10) Atomic Research.
11) Electronic, medicament, food.\t
