Product Overview

Description



Head


1SPECIFICATION


  Double Disk Winder





Application:


The machine is mainly used in winding-up and packing of aluminium-plastic compound pipe cross-linking compound pipe and other plastic soft pipes. It automatically adjusts winding speed and winding methord. It has two disk for continious winding. It adopts air-operated method. The wheel rib of the winding up wheel adopts air-operated opening and closing. It is equipped with a ray creel stand to automatically wind displacement. It reaches winding up orderly. The machine structure is compact. Its automatication is high. Its appearance is beautiful and its opration is conenient.





Main techinical standards:
































































modelSPS280SPS400SPS700SPS1250
winding diameter280mm400mm700mm1250mm
winding speed0.5-15m/min0.5-15m/min 0.8-8m/min0.8-5m/min
winding width220mm300mm400mm420mm
winded pipe specification12-16mm14-32mm14-63mm75-125mm
air pressure0.6Mpa0.6Mpa0.6Mpa0.6Mpa
appearance size2100x1000x1400mm2500x1150x1450mm4350x2100x2315mm4500x2250x2300mm
weight7000kg1000kg1500kg4500kg










If you are interested in our plastic extruder machine pls contact me by below:


-- Phone / Wechat / Whatsapp : +86 18921980633
