High Pressure Rubber Hydraulic Hose (R1/R2/1SN/2SN/4SH)
High pressure oil and ozone resistant power flex hose EN853 1SN Tube: Oil resistant synthetic rubber Reinforcement: one or two high tensile steel wire braid Cover: Oil, abrasion and weather resistant synthetic rubber Temperature: -40 °C to 100 °C
SAE 100R1/EN853 1SN
DN
Hose I.D
Wire O.D
Hose O.D
Working Pressure
Burst Pressure
Weight
inch
mm
mm
mm
MPa
MPa
kg/m
5
3/16
4.8
9.5
11.8
25
100
0.19
6
1/4
6.4
11.1
13.4
22.5
90
0.21
8
5/16
7.9
12.7
15
21.5
85
0.24
10
3/8
9.5
15.1
17.4
18
72
0.33
13
1/2
12.7
18.3
20.6
16
64
0.41
16
5/8
15.9
21.4
23.7
13
52
0.45
19
3/4
19
25.4
27.7
10.5
42
0.58
25
1
25.4
33.3
35.6
8.8
35
0.88
32
1 1/4
31.8
40.5
43.5
6.3
25
1.23
38
1 1/2
38.1
46.8
50.6
5
20
1.51
51
2
50.8
60.2
64
4
16
1.97
Product Name
hydraulic hose
Material
synthetic rubber
size
1SN,2SN,4SH
standard
DIN
color
black
Temperature
-40~+100°C
Detailed Images
Related Products
Packing&Shipping
1.The default is the wear-resistant woven strip packaging 2.If you need other packaging like wooden box and pallet,please contact us. 3.The volume is for 1 roll and the weight is for 1 m.
Company Introduction
FAQ
Q:I want to know the main products of your company. A:we Specialized in development,production and sales services of Oil cooler hose; Hydraulic Brake Hose, Air Brake Hose,stainless steel braided brake hose; Air Conditioner Hose,Power Steering Hose,High Pressure Rubber Hose, Assembly,also have all kinds of fittings.
