Vacuum Ointment/Cosmetic/Honey/Mayonnaise Mixing Homogeneous Emulsifying Machine
- Category: >>>
- Supplier: Nantong Sunway Machinery Manufacturing Co. Ltd.
Share on (62575167013):
Product Overview
Description
Product Description
Hand Sanitizer Gel Mixing Machine, Hand Saniziter Gel Making Machine is available for heating, melting, materials, it is ideal device for paste-cream products of middle and high grades. This equipment includes oil phase boiler, water phase and emulsification vessels, operation platform and control tank.
Usage and Application Field
The product is mainly applied in such industries as daily chemical care products, pharmaceutical industry, food industry, paint and ink, nanometer materials, petrochemical industry, printing and dyeing auxiliaries, pulp&paper, pesticide, fertilizer, plastic&rubber, electrics and electronics, fine chemical industry,etc. The emulsifying effect is more important for materials of high base viscosity and high solid content.
Technical Parameters
Item No. | Name | Materials, Name, Model | Place of Orign | Remark |
Configuration | ||||
1 | Main Vessel | Avaliable Volume:100L | Made by ourselves | Inner and outter polishing 300U |
a | Inside Vessel | Material SUS304L, Vessel Size:φ650*350*3mm | Made by ourselves | Heating power:2*9KW |
b | Interlayer | Material: SUS304,Thickness:3mm | Made by ourselves |
|
c | Outside Vessel | Pressure gauge vacuum, suction filter vent valve, vacuum mouth, mouth mirror, perfume spray ball, funnel | Outside | All sanitary fittings, thickness:4mm |
d | Stirring paddle, shaft | Using the paddle stirring; 304L material | Made by ourselves |
|
e | Stirring motor | Power:1.5KW Speed:0-60rpm/min | China | With Panasonic inverter |
f | Lower Dispersion motor | Power:4KW,Speed:0-2800rpm/min | China | With Panasonic inverter |
2 | Water tank | Avaliable Volume:90L | ourselves | Inner and outter polishing 300U |
a | Inside Vessel | Material:SUS304, Size:3mm*φ550*350 | ourselves | Heating power:2*9KW |
b | Interlayer | Material A3steel,thickness:3mm | ourselves |
|
c | Outside Vessel | Material SUS304,thickness:2mm | ourselves |
|
d | Stirring | Impeller agitator;material SUS304L | ourselves |
|
e | Stirring motor | Power:0.55KWSpeed:900rpm/min | China |
|
3 | Oil tank | Avaliable Volume:60L | ourselves | Inner and outter polishing 300U |
a | Inside Vessel | Material SUS304,Size:φ450*350*3mm | ourselves | Heating power:2*9KW |
b | Interlayer | Material A3steel,thickness:3mm | ourselves |
|
c | Outside Vessel | Material SUS304,thickness:2mm | ourselves |
|
d | Stirring | Impeller agitator;material SUS304L | ourselves |
|
e | Stirring motor | Power:0.55KW Speed:900rpm/min | China |
|
4 | Electric control cabinet | With frequency converter, electric component button, a temperature control meter. | China |
|
5 | Lifting system | Hydraulic lifting method; power: 1.5KW
| China | With limit |
6 | Dumping system | Manual dumping
| Made by ourselves |
|
7 | Vacuum pump | Water ring vacuum pump; power 2.2KW with stainless steel tank | China |
|
Machine Photos
