* Portable and delicate design, easy to operate
* Accurate pulse pace identification function
* High accuracy digital filter, automatic baseline adjustment
* Working modes: Manual / Auto / R-R Rhythm
* 112mm, 6 channel format recording, excellent automatic interpretation
* 800×480 graphic 7 inch color TOUCH SCREEN LCD to simultaneously display ECG information
* 250 patient cases storage ( SD card storage is Optional)
* Detailed patient information record
* Adapt to 110 ~ 230V, 50/60Hz power supply
* Built-in rechargeable Li-ion Battery support continuously working around 4 hours.
* USB/Rs232 Communication Port support USB storage, laser printer printing and PC ECG Software (Optional)
Lead
Standard 12 Leads
Lead Acquisition
12bit/1000Hz (synchronously 12 leads)
Work Mode
Manual / Auto / R-R Analysis
Filter
* AC Filter: 50Hz / 60Hz
* EMG Filter: 25Hz / 45Hz
* Anti-Drift Filter: 0.15Hz (Adaptive)
CMMR
≥ 120dB (with AC Filter)
Input Circuit
Floating: Protection circuit against Defibrillator effect
Input Impedance
≥ 50 MΩ
Input Circuit Current
≤ 0.05μA
Patient Current Leakage
< 10μA
Calibrating Voltate
1mV±2%
Voltage Tolerance
≥ ±500mV
Time Constant
≥ 3.2s
Frequency Response
0.05 ~ 160Hz (-3db)
Noise Level
< 15μV p-p
Inter-channel Interference
≤ 0.5mm
Sensitivity
Auto, 2.5, 5, 10, 20, 40mm/mV (±3%)
Recording Mode
* 3ch, 3ch+, 3ch+++, 6ch
* Default Man.Mode is 3ch format
* Default Auto.Mode is 6ch format
Paper Speed
6.25, 12.5, 25, 50mm/s (±3%)
Paper
112mm x 20m roll paper
Working Environment
Temperature 5 ~ 40℃; Humidity 25 ~ 95%
Power Supply
* AC 110 ~ 230V (±10%), 50/60Hz(±1Hz), 40VA
* DC Built-in rechargeable battery, 14.4V (2000mAh)
Dimension/Weight
300mm x 230mm x 72mm, 2.8Kg
Our Company
With years of export experience along with excellent quality, advanced services and competitive prices, Proway has won numerous customers' trust and support. In order to better control the quality and delivery time, we built our own factory Suzhou Lexison MediTech in 2012. Our main products are various Patient Monitors, Syringe Pumps, Infusion Pumps and various medical instruments for veterinary use.
Our value Message is "QUALITY IS OUR CULTURE"! "WITH US, YOUR MONEY IN SAFE, YOUR BUSINESS IN SAFE"
Recommend Products
Packing & Delivery
Packing
Carton box packing with foam filled.
Delivery
For the order which less than 20units, more of the customers choose the shipment by Express Courier or by Air Cargo. Our normal Lead Time is within 7working days after payment.
Certifications
FAQ
1. What is your MOQ?
---- 1Unit/1pc
2. What is your Lead Time?
---- For the normal order, 7working days after payment.
3. What is your company's Payment Term?
---- TT(Wire Transfer), PayPal, Western Union, Credit Card and E-checking are available.
4. What is your Warranty Period?
---- 24months warranty period and lifetime technical support.
5. Do you accept Money Refund?
---- Yes, we accept Full Money Refund once the customer received the goods with quality problem.
