Product Overview

Description

Product Description

Extruded nylon is the most important engineering plastics.The product is widely used in almost every fields and it's the most widely used plastic of the five engineering plastics.
PA6 is a translucent or opaque milky crystalline polymer which is made from polymerized caprolactam monomer at high temperature.The material has the most superior comprehensive performance including mechanical strength, stiffness, toughness, mechanical shock resistance and wear resistance.All these properties combined with good electrical insulation and chemical resistance make PA6 a general purpose grade material for manufacture of mechanical components and maintainable parts.

The orginal color of the PA6 is .milky white.

Our PA6 rods and sheets are made of BASF or DSM raw material,It has excellent mechanical properties.

Our PA6 rods have good roundness and straightness,very suitable for automaic lathe processing.

Our extruded nylon rod series also includes PA66 rod,PA1010 rod etc.

JG-PA6 PHYSICAL PROPERTY TABLE
	Content/Feature/Property	Test method	Unit	Value
Mechanical property	Tensile strength	ISO 527-1, 2	Mpa	78
		Bending strength	ISO 178	Mpa	100
		Bending tensile stress	ISO 527	Mpa	76/-
		Stretching strain at break	ISO 527	%	>50
		Tensile modules of elasticity	ISO 527	Mpa	3250
		Compressive stress under 1% and 2% normal strain	ISO 604	Mpa	24/46
		Pendulum impact test	ISO 179/1eA	kj/m²	5.5
		Rockwell hardness		HR	R106
Physical property	Density	ISO 1183	g/cm3	1.14
		Water absorption (23℃ water soak for 24 hours)	ISO 62	%	1.28
		Coefficients of linear thermal expansion (23-100℃ average value)		m/(m.k)	90×10^-6
		Flammability (UL)	UL94		HB
Heat resistance	Melting point		℃	220
		Temperature resistance (continuous)		℃	80
		Temperature resistance (short time)		℃	120
Insulating property	Dielectric strength	ISO 60243	kv/mm	25
		Volume resistance	ISO 60093	Ω·cm	1O¹⁴
		Surface resistance	ISO 60093	Ω	1O¹³
		Relative permittivity -100HZ/1MHZ	ISO 60250		3.9/3.3
Chemical property	Acid resistance			+/0
		Alkali resistance			+
		Carbonation resistance			+/0
		Aromatic compounds resistance			+/0
		Ketone resistance			+
Other	Adhesion			+
		Friction coefficient			0.36
		Food contact			+

Remark:
1.Above data is only for reference.It may vary according to different processing method and sample.
2.These data can't be simply transferred to the finished parts.The applicability of materials for specific applications should be testes by the processor and user.
3.These technical parameters are used as a help.They do not represent a promise of performance.
4.Above specification "+" represents positive, "-" represents negative, "0" represents it depends.

Widely used in machinery, automotive, electrical, chemical, aviation, marine and other fields, replacing copper and wearing parts of other metal materials such as bearing, shaft sleeve, muff, gear, rack, pulley, slider, nut, screw, piston ring, chain wheel, belt pulley, pump impeller, valve seat and so on.
