  • Биполярный контроль температуры KSD303, 250 В, 16 А, 50 200 градусов, защита от перегрева
Биполярный контроль температуры KSD303, 250 В, 16 А, 50 200 градусов, защита от перегрева
Биполярный контроль температуры KSD303, 250 В, 16 А, 50-200 градусов, защита от перегрева
Биполярный контроль температуры KSD303, 250 В, 16 А, 50-200 градусов, защита от перегрева
Биполярный контроль температуры KSD303, 250 В, 16 А, 50-200 градусов, защита от перегрева
Биполярный контроль температуры KSD303, 250 В, 16 А, 50-200 градусов, защита от перегрева

Биполярный контроль температуры KSD303, 250 В, 16 А, 50 200 градусов, защита от перегрева

Share on (62585412459):


Price:0,70 $ - 0,90 $

Quantity:


Product Overview

Description




Product Description

 Overheating Protection Bipolar Temperature Control KSD303 250V 16A 50 To 200 Degrees

Place of originMade in China
Raw materialsliver, copper, plastic, metal, aluminum
modelKSD303
Electrical RatingAC250V  15A (resistance load), Max. Current: 20A
Action Temperature range50~200 degree
Recovery and action temperature difference10 to 25 degrees or according to client's request.
Temperature deviation±3 / ±5 / ±10 degree or according to client's request
Circuit resistance≤50mΩ (Initial value)
Insulation resistance≥100MΩ (DC500V Normal State)
Dielectric StrengthAC50Hz 1500V / min, no breakdown blinding (Normal State)
Life cycle≥100000 times
Contact typeNormally closed
Delivery time7 to 15 working days
Scope of applicationKSD303 is used for instant electric water heater, electric heating equipment, electric welding machine, steam heater, high power machinery and equipment and electric products etc
