Huanghe Whirlwind Mobile Six Seats Medical Emergency Hospital Ambulance Vehicles
Huanghe Whirlwind Mobile Six Seats Medical Emergency Hospital Ambulance Vehicles
Huanghe Whirlwind Mobile Six Seats Medical Emergency Hospital Ambulance Vehicles
Huanghe Whirlwind Mobile Six Seats Medical Emergency Hospital Ambulance Vehicles
Huanghe Whirlwind Mobile Six Seats Medical Emergency Hospital Ambulance Vehicles
Huanghe Whirlwind Mobile Six Seats Medical Emergency Hospital Ambulance Vehicles
Huanghe Whirlwind Mobile Six Seats Medical Emergency Hospital Ambulance Vehicles

Huanghe Whirlwind Mobile Six Seats Medical Emergency Hospital Ambulance Vehicles

Share on (62585926100):


Price:$70,000.00 - $75,000.00

Quantity:


Product Overview

Description


Product Description
Specification
Parameters  Table
Vehicle model
X6533TB-M6
Length* Width* Height(mm)
 5341*2032*2480(outside)
 2922*1720*1778(inside)

Wheelbase(mm)
3300
Maximum total mass(kg)
2510
Maximum speed(km/h)
145
Tire size
215/75R16LT
Passager Number
7
Motor model
DURATORQ4D206H
Fuel type
Diesel
Vehicle model
X6533TB-M6
Drive type
4x2 LHD
Vehicle curb mass:(kg)
2510
Wheelbase(mm)
3300
Dimension of Patient's
compartment(mm)
2922×1720×1778
Overall dimensions (mm)
5341×2032×2480
F/R Wheel tread (mm)
1655 / 1650
Fuel tank capacity (L)
70
F/R Overhang (mm)
1190 / 1120
Brake system
4 wheels disc brake
Fuel consumption (L)
10.8
GVW (kg)
3250
Enging
3TZ
Fuel type
Petrol
Displacement (ml.)
2693
Emission standard
Euro V
Maximum power (kw)
110
Gearbox
Manual 5 speed
Tires
195R15C / 4
Max. speed (Km/h)
150











Standard configuration
of vehicle
1. JIANGLING Chassis: 1unit
2. Anti-skidding floor in Patient's compartment: 1set
3. Integrated interior decoration: 1set
4. Partition wall: 1 set
5. Illuminating Light in Patient's compartment: 1set
6. Transfusion bracket: 1set
7. Medicine and instrument cabinet in Patient's compartment: 1set
8. Long bench:1set
9. Supply system of oxygen: 1set
10. Inverted power supply: 1set
11. External power supply: 1set
12. Ultraviolet radiation disinfector light:1pc
13. Outside identifying light: 1set
14. Flash alarm light bar: 1set
15. Ventilation system: 1set
16. Doctor chair: 1set
17. Self-lifting stretcher (Primary Stretcher): 1set
18. Adjustable scoop stretcher (Secondary Stretcher): 1set
19. Multifunctional operation panel: 1set
20. Fire Extinguisher: 2pcs
21. Crashworthy head restraint: 1set
22. Garbage bin: 1pc
23. Non-contact Interphone system: 1set
24. Special cabinet for stupefacient: 1set



Option
3TZ 2.7L Petrol engine + RHD

DK4B 2.5L Diesel engine + LHD
DK4B 2.5L Diesel engine + RHD

4RB2 2.4L Petrol engine + LHD
4RB2 2.4L Petrol engine + RHD

Engine made in Japan 2TR 2.7L Petrol engine + Manual Transmission + LHD
Engine made in Japan 2TR 2.7L Petrol engine + Auto Transmission + LHD
Packing & Delivery
According to the needs of customers, we can design a total solution, which can dock mobile medical vehicles in organizations, schools, companies, etc., or in geographically remote places with scarce medical resources, or in emergency disaster relief incidents, to meet the masses of people for superior medical resources and become a mobile hospital.
Company Profie
1. The space designed reasonable fully equipped with medical equipment.
2. Also there is much more extra space for optional device.
3. Standard double back door satisfy the treatment and transit for the patient.
4. famous brand with easy after-sales maintenance and economic price , save cost for big order.
5. According to the needs of customers can choose a variety of medical equipment.
FAQ
1.Do you have CE or ISO9001 certificate?

Yes ,we have both the CE certificate and ISO9001 certificate.

2.Is your trailer meeting our county standard ?
All our trailer will be made according to different countries standard , including wires , lights, gas etc . and will be tested on
road before delivery.

3.What is shipping packing?
Exporting wood package make sure trailer will be good until reaching to you.

4.What is payment method ?
T/T advance , trade assurance, western union, money gram.

5.Are you manufacturer?
Yes,OEM,we are manufacturer with own workshop,welcome to visit our factory if u have time.

6. Can your cart meet our country's standards?
we can do your order as your request to meet different standards.

7.What is the lifetime of the trailer?
The designed lifetime of trailer is 20 years. The guarantee of trailer is 5 years.

8.The trailer color can be customized ?
Yes , can , any color and any logo by stickers is available .

9.What is delivery time?
Usually delivery time is 3 weeks.
