Portable compress dental equipments unit 2hp 50l oil free air compressor
- Category: >>>
- Supplier: Zhejiang Shengyuan Compressor Manufacturing Co. Ltd.
Share on (62593337205):
Product Overview
Description
Product Display
Product Parameter
Model# | YY-550X2-55W/CD | YY-750X2-55W/CD | ||
Type | Oil Free Air Compressor | Oil Free Air Compressor | ||
Rated Input Voltage/Frequency (V/Hz) | AC-220V/50HZ | AC-220V/50HZ | ||
Rated Input Current (A) | 5.4A | 5.4A | ||
Rated Input Power (KW/HP) | 1.1KW (1.5HP) | 1.5KW (2HP) | ||
Speed (RPM) | 1380RPM | 1380RPM | ||
Air Flow Displacement | 204 L/min (7.2CFM) | 270 L/min (9.5CFM) | ||
Max. Pressure | 8Bar (116PSI) | 8 Bar (116PSI) | ||
Noise Level | 59dB | 59dB | ||
Working Temperature | MIN.0℃ ~ MAX. 40℃ | MIN.0℃ ~ MAX. 40℃ | ||
Maximum Pressure (Bar) | Continous | 7 Bar (101.5PSI) | 7 Bar (101.5PSI) | |
Intermitten | 8 Bar (116PSI) | 8 Bar (116PSI) | ||
Restart | 0 | 0 | ||
Compressor Pump Performance (Ltr/m @ Bar) | 0.0 BAR | 176Ltr/min | 184Ltr/min | |
2.0 BAR | 142 Ltr/min | 178 Ltr/min | ||
4.0 BAR | 114 Ltr/min | 156 Ltr/min | ||
6.0 BAR | 90 Ltr/min | 130Ltr/min | ||
8.0 BAR | 74 Ltr/min | 1l8Ltr/min | ||
Electric Motor | Wire material | Copper | Copper | |
Stator Size | 160 tablets | 160 tablets | ||
Stator & Rotator Sheets | Silicon steel sheet | Silicon steel sheet | ||
Tank | Capacity | 55L (12.2Gal) | 55L (12.2Gal) | |
Material | Q235 | Q235 | ||
Thickness | t=2.5mm | t=2.5mm | ||
Standard Equipment | Pressure Controller | 0.5-0.8 Mpa | 0.5-0.8 Mpa | |
Air Regulator with Valve | G1/4 with nozzle | G1/4 with nozzle | ||
Connecting Pipe Material | Soft Metal Tube | Soft Metal Tube | ||
Muffler | Three in one muffler | Three in one muffler | ||
Thermal Protector | NO | NO | ||
Condenser / dryer | YES | YES | ||
Power Cable | 3x1.0mm2x1.5m | 3x1.0mm2x1.5m | ||
Size& Weight | Net Weight (KG) | 51KG | 53KG | |
Machine Size | 705x350x585mm | 705x350x620mm | ||
Packaging | Carton | Carton | ||
Gross Weight(KG) | 53KG | 55KG | ||
Packaging Dimensions | 725x370x605mm | 725x370x605mm | ||
