Product Overview

Description



Product Description




Flat-Flex® conveyor belts have over 85 years of trusted performance, promoting maximum flow-through for many applications in
various industries. Flat-Flex® belts are USDA Accepted and designed to be cleaned-in-place. With more than five thousand belt
configurations available, Flat-Flex® belts can vary in materials used, wire diameter, spacing, design pattern and lateral width.



Features
The unique features of Flat-Flex conveyor belts offer numerous benefits that increase productivity, help contain costs and
improve your overall product quality, including:
* The largest proportion of open-mesh area available- up to 86%
* Easy to clean, clean-in-place design
* No-slip, positive drive
* Very low belt mass
* Smallest diameter end rolls and drive rolls
* Positive driven for accurate tracking
* USDA Accepted

Flat-Flex belts are available in a wide variety of materials, the standard is 302 stainless steel. Other materials available
include: 316 stainless steel, various carbon steel, and high temperature performance materials.
Flat-Flex’s C-CureEdge Technology is an available option for most Flat-Flex® belts. This technology eliminates the possibility of
the belt edge catching and tangling.


XT Code Reference
X426
X247
X327
X328
Mesh Size Available
42 x .062 (3/8”)
24 x .072 (1/2”)
32 x .072 (3/8”)
32 x .082 (3/8”)
Wire Diameter in inches
0.0625
0.072
0.072
0.082
Strands Per Foot
41.5
24
32
32
Pitch in inches
.286
.500
.375
.375
Opening between Wires in inches
.227
.428
.303
.293
Standard Edge Loop Size (inches +/-.0156)
0.281
0.281
0.313
0.313
XT Space Width (inches)
.875
.875
.875
1.00
Minimum Space Width (inches)
2
1.75
2.25
3.25
Minimum Sprocket Diameter (inches)
1.25
1.625
1.625
1.625
Weight Per Sq. Ft. (avg. in lbs.)
0.61
0.62
0.65
0.81
Maximum Belt Load per Sq. Ft. (lbs.)
3.5
13.8
15
15
Maximum Tension per Joint (lbs.)
15
18
18
22
Minimum Transfer Diameter (inches)
0.5
0.625
0.563
0.563
Width Tolerance (inches) max. width 168”
* 0” to 6” belt width: +/-1/32”
* 6” to 36” belt width: +/-1/16”
* 36” to 60” belt width: +/-3/32”
* Over 60” belt width: +/-1/8”
Typical Open Area (%)
71
74
71
67


Standard Belt Data
Flat-Flex is available in a wide range of wire diameters & pitches. The below data is an extract from our full range of
Flat-Flex belting. There is a wider range of pitch and wire diameter variations available, please ask our customer service team
or technical sales engineers if you do not see the specification you require.
