different types changeable IPL laser filters

Product Overview

Description

OEM service: High Quality 420nm, 430nm, 480nm, 530nm , 560nm , 590nm , 640nm , 690nm 750nm, 755nm , 760nm , 790nm , 810nm IPL filters for Cosmetic Applications







Features:



IPL Filter is the key optical element for IPL (intense Pulsed Light) machine, which filter the UV wave and reserve the useful wave from 400nm to 1200nm for cosmetic laser, such as hair removal, vascular and acne treatment.





Principle:



                                         IPL filter coating 695~1200nm



Details:



IPL filter specifications:

Common dimension: 34x10x8mm, 45x10x10mm Dimension Tolerance: +/-0.1  Thickness Tolerance: +/-0.2  Surface Quality: 60/40  Clear Aperture: >90%  Parallelism: 3 min  Wavefront Distorfion: 1/2 Wave at 632.8nm  Bevel: 0.2~0.4mmx45° Wavelength: 495~1200nm, 515~1200nm, 530~1200nm, 550~1200nm, 560~1200nm, 570~1200nm, 590~1200nm, 615~1200nm, 645~1200nm, 695~1200nm, 755~1200 nm, 780~1200 nm  Custom size and wavelength are available upon request.
