GEA NT150S plate heat exchanger gasket
- Category: >>>
- Supplier: Jiangyin Daniel Cooler Co. Ltd.
Share on (629473032):
Product Overview
Description
For plates:
*Our production capacity covers more than 300 specification and size plates, the plates function equals to the famous alfa laval, sondex etc brand PHE manufactures,;
*Plate Port diameter 29mm to Port diameter 328mm, plate width from 125mm to 995mm, height from 429mm to 2245mm,thickness from 0.5-1.0mm.
Plate material | Applicable fluids |
Stainless steel(SU304.316 ect) | Clean water, river water, edible oil, mineral oil |
Stainless steel & Ti, Ti-Pd | Sea water, salty water, salt compounds |
20Cr, 18Ni,SMO | Dilute sulfuric acid, water solution of salt matter, Inorganic solution |
Nickel | High temperature and high concentration of caustic soda |
Hastelloy | Concentrated sulfuric acid, Hydrochloric acid, Phosphoric acid |
Gasket
We produce and supply many kinds of gasket for plate heat
exchanger, certified by ISO9001,
Rubber Type | Flu rubber | EPDM | NBR |
Tensile Strength MPa | ≥13 | ≥16 | ≥17 |
Elongation % | ≥120 | ≥170 | ≥200 |
Shore A Hardness | 80±5 | 80±5 | 75±3 |
Tear Strength KN/M | ≤30 | ≤30 | ≤30 |
Compressive Deformation | 24h×23≤2.5 | 24h×23≤5 | 24h×23≤2.5 |
| 24h×180≤15 | 24h×150≤15 | 24h×125≤15 |
Ozone Resistance | Excellent | Excellent | good |
Gasket Material | Applicable Temperature | Applicable Fluids |
NBR | -15~+135 | Water seawater, Mineral oil, Saline |
EPDM | -25~+180 | Hot water, vapor, acid, alkali |
F26 | -55~+230 | Acid, alkali, fluids |
FTP | 0~+160 | concentrated acid, alkali, High temperature oil, vapor |
