For Basysprint UV Setter, UV Sensitive CTP Plate

Product Overview

Description



For Basysprint UV Setter, UV Sensitive CTP Plate





>High-quality aluminum substrate

>Complex grain structure&dense oxidized layer

>The substrate of hydrophilic treatment

>Perfect coating formulation

>Complete technical service system and sales network



Main Technical Specifications and Processing Conditions

Technical specifications	Sensitivity(mj/cm2	60-70
	Clear step on gray scale	3rd step, clear
	Dot reproduction(%)	2-98%
	Micro-line reproduction(um)	10-6
	Runlength	>100,000
Recommended Processing Conditions	Dilution ratio	Huaguang PD: water=1:4(by machine); water=1:6(by hand)
	Developer conductance(mS/cm, 25°C)	58-54(by machine);47-43(by hand)
	Developing TEMP	21-25
	Developing time(s)	30-50
	Contamination removal	Retouching paste: 40s Retouching solution:10s
	Gumming	A even, thin coating, 20ml/m2
	Baking	Oven: 240°C, 4-5mins; Motire: 260°C, 3-4mins



Positive ctcp plate is proper for precise color printing. It's a sort of light-decomposition plate.

The photosensitive layer decomposes when exposed too light and it is removed during developing.

So the non-image area is formed and the unexposed region turns out to be printing image area.

Generally speaking, during UV-CTP plate-making, we need to remove a larger area which takes longer time to expose and plate-making is slower than the negative plate comparatively.



The positive plate suitable for business printing has a good dot reproduction and processing adaptation.
