Veterinary equipment BR5000B ENT Endoscopic Detector endoscope ent

Product Overview

Description

 endoscope (integration type)

(1) technical parameters



1.built-in camera  1/3 SONY CCD



2. Resolution ≥420TV lines



3. Image magnification ≥2 times



4. Type of light source    LED, white light



5. Brightness of the light source    1000cd/m²



6. Diameter of Mirror tube    φ6mm±0.2mm



7. Length of the mirror tube    100mm



8. Color LCD monitor    8.5 inch (16:9)



9.AC input   100~240V, 50/60Hz  DC output: DC12V,2A



10. Gross weight    7.3kg



11. Package size   37*51.5*29cm



(2) components





Name	Quantity	Note
endoscopic detector host	one
pedal switch	one
gun head	one
power supply adapter	one
video adapter	one
video line	one
remote control	one
chart	one
power adapter	one

(3) Features



1.High-performance lens can bring light transmission to provide a guarantee for image clarity.

2.BR5000 series of endoscopy detector is mainly used for human eye can not observe or disassemble the measured object. 3.The product has a unique front LED light source, without additional lighting, high-definition stainless steel to lengthen the optical lens, built-in high-resolution color video camera, so that the parts of the image are checked to see more depth and clearer, more thorough .

4.Handheld probe can be more intuitive, put the imager of the measured parts displayed on the monitor quickly.
