cement clinker roller press

Product Overview

Description

Roller Press for Cement Clinker Pre-grinding Introduction In cement production line, both roller press and hammer mill can be applied in cement clinker pre-grinding process.

Cement clinker pre-grinding mill



is additionally installed in the upstream process of the tube or ball mill (hereinafter generically called the finishing mill), which is currently used for the cement finishing process. By crushing the clinker preliminarily with the pre-grinder, this equipment alleviates the operation load of the finishing mill (with considerable power consumption) to significantly reduce the power consumption rate, and moreover, increase the crushing capacity.

Roller Press for Cement Clinker Pre-grinding Features



1. The roller crusher can bring excellent material extrusion effects with large amounts of fine powder.

2. Advanced welding technology enables the roller crusher to have a service life of more than 8000 hours.

3. Forged with extrusion roller alloy steel as a whole, it has high loading capacity and reliable performance.



Type	Roller Diameter (mm)	Roller width (mm)	Main Motor Power (kw)	Average/max feedstock Granularity (mm)	Discharging Granularity (mm)	Treatment Capacity (t/h)	Weight (t)	Dimensions (mm)
								Length	Width	Height
P1003	1000	300	160*2	25/40	65%≤2mm 25% ≤0.08mm	50-70	33	3835	4510	1885
P1004	1000	400	200*2	25/40		65-90	36	4080	4600	1920
P1006	1000	630	315*2	25/40		105 -145	55	4526	5280	2200
P1204	1200	450	220*2	30/50		95-130	62	5500	4470	2340
P1205	1200	500	250*2	30/50		140-165	64	5550	4620	2390
P1208	1200	800	455*2	30/50		180-230	90	5608	5500	2460
P1406	1400	650	455*2	35/60		225-290	104	7205	5440	2610
P1408	1400	800	500*2	35/60		283-362	125	7400	5780	2610
P1410	1400	1000	630*2	35/60		283-362	135	6400	8990	3000
P1509	1500	900	710*2	35/60		340-460	163	6610	8860	3490
P1614	1600	1400	1000*2	35/60		650-750	190	7000	9320	3980
P1714	1700	1400	1250*2	40/70		710-830	240	7230	9420	4100
P1816	1800	1600	1600*2	45/80		800-1000	278	8000	11100	4550
