Ультразвуковой сварочный аппарат с солнечным коллектором хорошего качества

Product Overview

Description

ultrasonic solar collector welder in good quality

- Can custom made bench and tracks for customers

- Welding head can roate in 2 direction

- With pneumatic control for UP and DOWN of welding head



CAN WELD SOLAR FIN,  SOLAR PANEL / SHEET

 *Solar panel Dimension: (Max) 2500mm x 1500mm



*Tube for Pneumatic Cylinder: Ø8x5mm PU tube



*Welding speed: 5-6meter/minute







FEATURES:

1.Titanium alloy booster
2.Strong tool head, MADE OF STEEL
3.Reliable and stable performance

4.Welding is fast, and good quality
5.PLC control, smart

6.Easy maintenance

7.Usually can weld 6 meter per minute





APPLICATIONS:

1.for the solar heater industry

 2.For the aluminum plastic pipe industry





SPECIFICATIONS:

Machine Name	SOLAR PANEL WELDING EQUIPMENT
Model	HN-SW01	HN-SW02
Ultrasonic Power	3000 W	2200 W
Ultrasonic Frequency	20Khz	20Khz
Copper Pipe(riser)	Ø7-12mm, MAX Length2500mm	Ø7-12mm, MAX Length2500mm
Aluminum Pipe(riser)	Ø7-12mm, MAX Length2500mm	Ø7-12mm, MAX Length2500mm
* Copper Panel	MAX Length 2500mm, Thickness 0.1-0.2mm	MAX Length 2500mm, Thickness 0.1-0.2mm
* Aluminum Panel	MAXLength 2500mm, Thickness 0.13-0.45mm	MAX Length 2000mm, Thickness 0.13-0.45mm
Standard Speed	1 meter / 8 seconds	1 meter / 10 seconds
Speed Control	adjustable	adjustable
Power Supply	110-240V, 50/60Hz	110-240V, 50/60Hz
