Flexographic Photopolymer Plates, 1.70mm Flexo Plates
- Category: >>>
- Supplier: Hangzhou Lecai Advertisement Printing Material Co. Ltd.
Share on (682403858):
Product Overview
Description
Flexographic Photopolymer Plates, 1.70mm Flexo Plates
Product Description
Type | R-170L |
Thickness (mm) | 1.70 |
Rigidity(Shore A) | 60±2,70±2 |
Recommended relief depth (mm) | 0.7-0.9 |
Image reproduction | 2%-98% |
Maximum line (line/inch) | 150 |
Minimum isolated line | 0.10mm (0.004inch) |
Minimum isolated dot | 0.15mm (0.006inch) |
Suitable ink | Suitable for water and alcohol-based ink, incompatible with oil-based ink, hydrocarbon solvent or the ink containing ethyl acetate of more than 25% |
Mainly applicable field | Film, label, flexible package, carry bag, folded paper box |
Maximum Size | 1270×2032mm (50×80 inches) |
Storage-raw plates | Unexposed plates should be stored in cool areas (4-32°C) away from heat. The plates must be placed flatly, and protected from contacting UV light. It is recommended to unpacked and handled in yellow light. |
Storage-finished plates | Printing plate should be avoid excessive white light, irradiating from sunlight and exposing in high concentrated ozone environments for a long time either. After being unloaded, the plates should be cleaned thoroughly. |
Guarantee Period | Under the recommended storage condition, guarantee period for Huaguang Flexographic Printing Plate is for 12 months. |
Back exposure (seconds) | 20-60 |
Main exposure (minutes) | 8-20 |
Rinsing (minutes) | 5-7 |
Marks: All the above data is depended on the plate-making device in our factory.
Due to the different requirements of plate-making device, the above recommended time can be changed suitably.
Customers should do test on their own device for optimum plate quality.
Packaging & Shipping
1. If the gross weight of photopolymer plates are lower than 50 kgs, you can choose it by Express Courier Service.
2. If the gross weight of photopolymer plates are 55 kgs-200 kgs, you can choose it by Air.
3. If the gross weight of photopolymer plates are more than 700 kgs, you can choose it by Sea.
Our Services
1. Samples available, we often send 1 carton of flexo plates to customer for sampling.
2. Sizes of flexo plates can be produced according to customers'demand.
3. We supply online technical support. If there is any problem, we will coordinate our engineers to help you solve the problem via e-mail/Tel/Video.
4. We have a tracking service every month to care about our products, if any problem, we will help you and learn from you together to solve the problem.
