Metal Zipper Slider Die casting machinery for making zipper slider

Product Overview

Description

AL Die-casting machine  for making zipper slider







1.metal zipper slider making machine
2.full automatic,labor saving
3.microcomputer automatic melting
4.real-time control



A:203
B:120
C:60
D:ø32
H:228
Emin:100
Emax:250

Specifications		Unit	DC12
Clamping Unit
Clamping Force		KN	120
Clamping Stroke		mm	130
Ejector Force		KN	12
Ejector Stroke		mm	40
Die Height (Min.-Max.)		mm	100-250
Platen Size(H x W)		mm	305¡Á305
Space Between Tie Bars		mm	203¡Á203
Tie Bar Diameter		mm	32
Casting Unit
Shot Position (0 = center)		mm	0-30
Max. Casting Force		kN	17
Casting Stroke		mm	80
Transverse Stroke		mm	140
Injection Plunger Diameter		mm	3036
Shot Weight (Zn)		Kg	0.280.4
Motor Power		kW	4
Others
Hydraulic Working Pressure		MPa	6
Hydraulic oil Tank Capacity		dm3(kg/Zn)	22(145)
Consumption	Oil	Kg/h	3.2
	Electric	kW	22
	Gas	M3/day	49
Oil box Cubage		L	150
Electricity Power		kW	1.5
Machine Weight		kg	1600
Machine Dimension(LxWxH)		L¡ÁW¡ÁH	3100¡Á1070¡Á1760
