EVA injection machine

Work Stations

stations

2

Clamping Force

kgf

150000

Mould PlateSize

mm

2(290X550)

Mould Height

mm

100-210

Mould-Opening Stroke

mm

350

Heating Power

kw

8.04

Injection System

Injector

1

Diameter of Screw

mm

60

Injection Cap (Max)

cc

860

Injection Pressure

kg/cm²

60-110

Injection Speed

cm/sec

0-10

Rotating Speed of Screw

r.p.m

0-190

Temperature Control

section

4

Heater Barrel

kw

6.05

Heating Plate

kw

25.6

Hydraulic System

kw

22

Vacuum Pump

kw

2.2

Cooling Fan of Barrel

HP

1

Total Electricity

kw

50

Oil Tank Size

L

500

Machine Weight

kg

8000
