One Step Closure for Wireless (OSCW antenna connector)

Product Overview

Description

Features Specifications:



The One Step Closure for Wireless (Feeder Splice Closure/Gel Seal for In-line and Antenna Connector) is a weatherproofing system sealing jumper-to-feeder and jumper to-antenna connectors, exposed to the outside environment. The housing contains an innovative gel material and provides an efficient moisture block.



The Main Models Include:

GSIC-100L, GSIC-100S



Technical Parameter:

1, Material: hign-intensity engineering plastic, no metal parts
2. Working Temperature: -40 degrees centigrade~+90 degrees centigrade
3, fireproof: HB
4. waterproof: IP68
5. ice-snow Resistance: up to 100 mm, no water leakage, no shape change

6. rainstorm resistance: 100E150mm/h
7. corrosion and ultra-viole resistance: H2S, passed ultra-viole test

8. Life / duration: 25 years



Remarks: provide customization service
