PTO wood debarker wood peeling machine wood working machine

Product Overview

Description

Advantage:

1. wood log debarker is groove peeling machine adopts roller type peeling.

2.The structureof wood log debarker is strong rigidity, low failure rate and long service life.

3.It consists of peeling roller feeding mouth out skin mouth out of wood mouth power transmission device five parts.

4.Wood log debarker  break the traditional rolling drum wood peeling machine,discharge into the material will stop faults.

5.The wood exports and wood export separation, realize a continuous work.



Wood debarker working principle

1.This machine is with step type peeling tooth tooth rotor produced unique force,

2 making lumber section in the bunker tank within plate cycle of do circular motion,

3.wood log debarker also around the wood period of their own axis do rotary motion.

4.Wood segment , bunker tank and comb plate between the friction on impact extrusion and stripping,

5.leading to bark and tree trunk fast break down and stripping

6. wood debarker machine is mainly comprised of feeding mechanism discharge mechanism cutter drive system chassis components, etc.

Wood debarker using range

1.Wood log debarker is used for fiber board factory in paper mill ,veneer rotary and cut wood pulp factory .

2.On eucalyptus, poplar wood and popularization of the effect is really good.

3.Wood log  debarker is suitable for assembly line work supporting equipment.





wood log debarker technical parameters

technical specification	Six meters single stick	Nine meters single stick	Twelve meters single stick
Capacity	5-10t/h	10-15t/h	15-25t/h
Power	7.5*2kw	7.5*2kw	7.5*2kw
Length(mm)	6300	9000	12600
width(mm)	1310	1500	1500
height(mm)	1550	1700	1700
Weight(t)	3t	4t	7.5t

 The wood log debarker pictures
