Professional Woven Bag Six Shuttle Circular Loom Plastic Weaving Machine PP Woven Bag Making Machine For Square Bag

Product Overview

Description

Professional Woven Bag Six-Shuttle Circular Loom Plastic Weaving Machine PP Woven Bag Making Machine For Square Bag

a. With the scroll transmission by little cam and swing-arm wheel, the machine runs easily and stably.

b. Thanks to the removal of the sliding block and rod, the easily torn and worn parts have been reduced.
c. The whole mechanism adopts scroll transmission, the lubricant will never be used.
d. With the detector for warp-breaking, weft-breaking and weft-ending, the sensibility for automatic stop becomes reliable.
e. With frequency control, the speed governing becomes more convenient and stable.
f. The intelligent micro-computer controlling system can be installed, if required. It can adjust the weft density and compensate the weft density in case of weft-breaking, which can put and end to the problem of low density and improve the evenness of woven fabrics. Moreover, it can achieve the online remote management, which saves labor intensity and improves business management.
g. It is a patent device. (Patent No.: ZL 200820166333.1, ZL201120310697.4)





Model No.	YF-XT-850/6
Number of Shuttle	6
Folding Width of Weaving (mm)	350-850
Max. Number of Warp	720/864
Rotational Speed of Main Body (r/min)	120-160
Production Capacity (m/min) (40 warps /100mm)	1.8-2.4
Power of Main Motor (kw)	2.2
Gross Power of Motor (kw)	2.7
Approx. Weight (kg)	2200
Installing Dimensions (LxWxH) (mm)	9000x2300x2730
