1.2 MM flux cored wire E70C 6M metal flux cored welding wire E70C 6M
- Category: >>>
- Supplier: Hebei Yichen Industrial Group Corporation Limited
Share on (718468867):
Product Overview
Description
1.2 MM E70C-6M welding material manufacturer
Specification conformance
AWS A5.18 E70C-6M
Dia: 1.2mm/1.6mm
Description and Using Scope
YC-YJ70C-6M is metal-cored flux cored wire. It has a smooth stable arc transfer, spatter free, excellent bead contour, with a high deposition rate and nearly free of slag weld bead. Used in flat position and horizontal fillet welding. This metal cored wire may be used on welding mild steel and low alloy steel, such as ship, steel structure and bridge.
Shielding Gas: Ar 75% + CO2 25%
Chemical Composition of deposited metal (%)
Item | C | Mn | Si | P | S | Ni | Mo | Cr | V |
0.06 | 1.34 | 0.32 | 0.012 | 0.01 | / | / | / | / |
Mechanical Properties Of Deposited Metal
Item | Yield Point (MPa) | TensileStrength (MPa) | Elongation δ5 (%) | Charpy V-notch Impact Toughness | ||
Test Temp. (°C) | Impact Energy (J) | Average (J) | ||||
480 | 570 | 29 | -20 | 130 | / | |
Size and Recommended Current (DC+) and Voltage Range
Size | Voltage Range | Current (DC+) | Ar/CO2 flow(L/Min) |
1.2mm | 25~32 | 200~350 | 15~25 |
1.6mm | 25~35 | 220~400 | 15~25 |
Procedures may vary with change in position, base metals, filler metals,equipment and other changes.
