high pressure hydraulic 1/2 BSPP ball valve spare parts
- Category: >>>
- Supplier: Ningbo Huarui Automation Equipment Co. Ltd.
Share on (720921754):
Product Overview
Description
2 way female BSP 2 x 1/2" steel full port ball valve WOG 7250psi
HYDRAULIC BALL VALVE
Female 2 x BSP 1/4"
2 way full port
High pressure 7250 wog
Steel material seal
Symbol:
Overall Dimension:
PORT:
Specific dimension sheet:
| Model | PN(Bar) | DN | LW | RA | d1 | i | L | L1 | B | H | h1 | h2 | SW1 | SW2 |
| KHB-G1/2 | 500 | 13 | 12 | G1/2 | 16 | 83 | 48 | 35 | 49 | 17 | 40 | 09 | 30 |
Material sheet:
Dimension Sheet:
| KHB Series Ball Valve | ||
| Size | Diameter | Pressure |
| 1/8" | 4mm | 7250psi |
| 1/4" | 6mm | 7250psi |
| 3/8" | 10mm | 7250psi |
| 1/2" | 13mm | 7250psi |
| 1/2" | 16mm | 5800psi |
| 3/4" | 20mm | 5000psi |
| 1" | 25mm | 5000psi |
| 1.1/4" | 32mm | 5000psi |
| 1.1/2" | 40mm | 5000psi |
| 2" | 50mm | 5000psi |
Specifications:
HYDRAULIC BALL VALVE MODEL:
HRPC hydraulic ball valves with models of KHB, KHB3K, VH2V, VH3V, BKH, KHP, YJZQ, QJH, Q11F...
BALL VALVE SIZE:
Connector size from 1/8 inch to 2 inch,
Diameter from 4mm to 50mm,
Pressure from 1.6MPa to 50MPa.
HYDRAULIC BALL VALVE CONNECTORS:
Female thread BSP, NPT, PT (1/8"~2")
Male thread M, LR, SR (M16*1.5~M60*2)
HYDRAULIC BALL VALVE MATERIALS:
1.Carbon Steel
2.Stainless Steel (SS316, SS304)
HYDRAULIC BALL VALVE SURFACE DISPOSAL:
1.Blank-Phosphoric polish (black color)
2.G-electroplated yellow zinc (yellow color)
3.G-electroplated yellow zinc (white color)
More products for your to choose:
Company Information
we are producing ball valve and hydraulic cylinders with quick delivery and competitive price. Ball valves covers the size from 1/4 inch to 2 inch in 2-way & 3-way type, with the materials of carbon steel, stainless steel and brass, connection type include female thread, male thread, flange, manifold mounting.
Besides, customers can specify the surface disposal, such as Blank-Phosphoric Polish, G-Electroplated Yellow (or White) Zinc. and the handles can be designed for special requirements.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 3-5 days if the goods are in stock. or it is 20-30 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance ,balance before shippment.
