Pneumatic Spot Welding Machine
- Category: >>>
- Supplier: Shijiazhuang Suncel Trade Co. Ltd.
Share on (726007415):
Product Overview
Description
Pneumatic Spot Welding Machine
Our Factory makes Spot Welding Machine, Wire Cutting and Straintening Machine, Wire Mesh Welding Machine, Wire Mesh Weaving Machine.
| Type | DN-35 | DN-55 | DN-75 | DN-100 | DN-120 |
| Item | |||||
| Rated input voltage | 1-380V/50Hz | ||||
| Rated input capacity | 35kVA | 55kVA | 75kVA | 100kVA | 125kVA |
| Rated input current | 92A | 145A | 197A | 263A | 315A |
| Rated load cycle | 20% | ||||
| Arm length | 500 Can be Longer | ||||
| Arm distance | 200mm | ||||
| working travel of electrode | 80mm | ||||
| Max.presure of electrode | 470kgf | 1200kgf | 1200kgf | 1200kgf | 1200kgf |
| the presure of gas | <O.6Mpa | ||||
| Welding thickness | 1-3mm | 1.2-5mm | l.5-6mm | 1.5-7mm | 2-9mm |
| The flow of cooling water | 6L/min | 8L/min | |||
