Product Overview

Description

iron floor grid

floor bar grating

welded grating

ISO COMPANY, GRATING SPECIALIST! Ms. Amy

******************************************************************************

Contact information:

Sales Director: Amy

Fax: +86 574 88073967,

******************************************************************************

There are three production lines in our company, and 85% of steel gratings are exported to the worldwide with perfect quality. There are many regular grating customers in USA Houston, Ohio, Charttle, LA, MiddleEast, AUS, Europe and Southeast so on.
This company is specialized in manufacture and exports all kinds of steel gratings with the best quality, competitive price and faster delivery time. Such as steel mill black and hot dip Galvanizing and stainless grating flooring walkway, platform and steel structures, stair tread, well cover, trench cover, compound gratings, storage shelves, ladder, fences and handrail so on for construction project, oil project, seaport, power plant, water plant, defense project, chemical factory and so on.

Ningbo Lihong Steel Grating Co., Ltd

STEEL GRATING SPECIALIST, ISO COMPANY

Sales Director: Amy

No.	Item	Description
1	Bearing Bar	25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10---100x10mm etc; I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc US standard: 1'x3/16', 1 1/4'x3/16', 1 1/2'x3/16', 1'x1/4', 1 1/4'x1/4', 1 1/2'x1/4', 1'x1/8', 1 1/4'x1/8', 1 1/2'x1/8' etc
2	Bearing Bar Pitch	12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
3	Twisted Cross Bar Pitch	38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2' & 4' etc
4	Material Grade	ASTM A36, A1011, A569, Q235, S275JR, SS304, Mild steel & Low carbon steel, etc
5	Surface Treatment	Black, self colour, hot dip galvanized, painted, spray coating
6	Grating Style	Plain / Smooth, Serrated /teeth, I bar, serrated I bar
7	Standard	China: YB/T 4001.1-2007,  USA: ANSI/NAAMM(MBG531-88), UK: BS4592-1987,  Australia: AS1657-1985, Japan:JIS
