AT series copper busbar 30W

Product Overview

Description

Copper Busbar/Pan Assembly

Application:

 AT Series of three phase and neutral distribution boards are availabe with a fixed load or split load pan assembly. The incoming can be 125A and 250A with different thickness of the main copper bar, din rail slot to allow the fixing of a incomer and various other modular devices. The incoming device must be selected and fitted by the installer.

 Specification:

Service voltage:	AC 415 / 240 / 120V
Rated insulation voltage:	600V
Frequency:	50 / 60Hz
Ambient temperature:	50°C
Covers the range from :	12W,18W, 24W, 30W, 36W, 42W, 48W, 54W, 60W, 66W, 72W with main breaker
Incoming:	MCB, ELCB, ISOLATOR, MCCB

Production Process:



PACKING:



Each one packed with Carton box. Export Packing suitable for shipment
