original cummins!!! Cummins Marine Engine NTA855 M350 /NTA855 M for boat

Product Overview

Description

SHANGHAI STONE DIESEL ENGINE CO.,LTD CAN SUPPLY CUMMINS ENGINE  NTA855 M350 /NTA855 M MARINE ENGINE.



Engine Model  NTA855-M (cummins NTA8855 M350 marine engine)

Displacement: 14.0 litre [855 in.3] Aspiration: Turbocharged/Aftercooled
Bore: 139 mm [5.50 in.]
Stroke: 152 mm [6.00 In.]

Fuel System: PT Advertised Power  261 [350] @ 1800
Cylinders: 6

Rating Type  Continuous

Rated Engine Power  kW [HP] 261 [350]

Rated Engine Speed   RPM 1800

High Idle Speed Range  RPM 1962 - 2106

Idle Speed Range  RPM 575 - 675

Engine Torque  N•m [ft lb] 1384 [1021]

Brake Mean Effective Pressure  kPa [PSI] 1241 [180]

Compression Ratio   14.5:1

Piston Speed  m sec [ft min.] 9.1 [1800]

Maximum Torque Capacity from Front of Crank**

Firing Order  1-5-3-6-2-4

Fuel System

Fuel Consumption  litre hr [GPH] 66.4 [17.6]

Approximate Fuel Flow to Pump   litre hr [GPH] 211 [56]

Fuel Rail Pressure Range  kPa [PSI] 1116 [162]

Weight (Dry)

Engine Only   kg [lb] 1303 [2870]

With Heat Exchanger Cooling System  kg [lb] +127 [280]

Air System*

Intake Manifold Pressure  mm Hg [in. Hg] 940 [37]

Intake Air Flow  litre sec [CFM] 380 [800]

Heat Rejection to Ambient  kW [BTU min.] 33 [1900]

Minimum Ambient Temperature for Cold Start (No Aids)   °C [°F] 0 [32]

Exhaust System

Exhaust Gas Flow (after turbine)   litre sec [CFM] 880 [1850]

Exhaust Gas Temperature (after turbine)    °C [°F] 427 [800]

Cooling System

Heat Rejection to Engine Coolant  kW [BTU min.] 220 [12,500]

Engine Water Flow    litre min. [GPM] 427 [113]

Raw Water Flow  litre min. [GPM] 234 [62]

Pressure Cap Rating w Heat Exchanger  kPa [PSI] 103 [15]

Cummins engine for marine (Cummins NTA855 M)



Cummins NTA855 M is applied for Fishing boat, Tug boat, Steel vessel, etc.



Cummins NTA855 M is very popular in medium vessel market, like Singapore, Malasiya, Indonesia, Croatia etc.



Cummins NTA855 M Features:

1. Cummins NTA855 M With turbocharger & Aftercooler

2. Cummins NTA855 M High medium continuous duty

3. Cummins NTA855 M installs on PT Fuel pump

4. Cummins NTA855 M fits to Keel cooling or heater excharger

5. Cummins NTA855 M can be up to 450 HP (Max. Power )

6. Cummins NTA855 M equips with Holset turbocharger



Cummins marine engine Model Power (KW) Power(HP) Max Speed (RPM)

Cummins NTA855 M350 261KW 350HP 1800RPM

Cummins NTA855 M400 298KW 400HP 2100RPM

Cummins NTA855 M400 298KW 400HP 1800RPM

Cummins NTA855 M450 336KW 450HP 2100RPM

General data of Cummins NTA855-M350 Marine Propulsion Engine
Engine Model	Cummins NTA855-M350
Type	6 cylinder in line
Rating Type	Continuous
Displacement	14 L
Bore&Stroke	140×152 mm
Weight (Dry) – Engine Only	1303 KG
Weight (Dry) – Engine With HeatexchangerSystem	1430 KG
Technical data of Cummins NTA855-M350 Marine Propulsion Engine
Aspiration	Turbocharged/Aftercooled
Fuel System	PT Pump
Coolant Flow to Engine Heat Exchanger	234 l/min
Minimum Idle speed Setting	575-675 RPM
High Idle Speed Range	1962-2106 RPM
Normal Idle Speed Variation	50 RPM
Compression ratio	14.5:1
Piston Speed	9.1 m/sec
Firing Order	1-5-3-6-2-4
Performance Date of Cummins NTA855-M350 Marine Propulsion Engine
Rated Output/Speed	261KW/350HP/1800RPM
Max torque/Speed	1385N.m/1500RPM
Brake Mean Effective Pressure	1243 KPa
Fuel Consumption/rated speed	66 l/hr
Approximate Fuel Flow to Pump	198 l/hr





NT855-M CUMMINS MARINE ENGINE

NT855-M270 SO13011 270/1800

NT855-M300 SO13012 300/1800

NT855-M240 SO13058 240/1800

NT855-M250 SO13417 250/1800

NT855-M280 SO13418 280/1800

NT855-M300 SO13419 300/1800

NT855-M200 SO13421 220/1800

NT855-M400 SO13520 400/2100

NTA855-M400 SO13096  400/2100

NTA855-M350 SO13519 350/1800

NTA855-M350 SO13273 350/1800

NTA855-M450 SO13521 450/1800

NTA855-M450 SO13458 450/1800

NTA855-M400 SO13496 400/1800



NT855-M CUMMINS MARINE ENGINE FOR GENERATOR

NT855-GM SO13434 173/1500

NT855-GM SO13465 205/1500

NT855-GA(M) SO13466 231/1500

NT855-G(MF) SO13487 179/1500

NTA855-D (M)CUMMINS MARINE ENGINE FOR GENERATOR

NTA855-G2M SO13019 284/1500

SO13525 284/1500

NTA855-G1M SO13051 287/1800

NTA855-G1M SO13065 240/1500

NTA855-G2M SO13140 313/1800

NTA855-G1MF SO13325 240/1500

NTA855-G2MF SO13326 284/1500

NTA855-G1M SO13392 240/1500

NTA855-G4M SO13396 317/1500

NTA855-G1M SO13453 287/1800

NTA855-G1M SO13467 240/1500

NTA855-G1A(M) SO13468 261/1500

NTA855-G2M SO13469 284/1500

NTA855-G2A(M) SO13470 310/1500

NTA855-G4M SO13471 317/1500

NTA855-G2MF SO13490 284/1500

NTA855-G1MF SO13495 287/1800

NTA855-G2M SO13504 284/1500

NTA855-D(M) SO13513 300/1500



 CUMMINS MARINE ENGINE NT855-M SO13011
CUMMINS MARINE ENGINE NT855-M SO13012
CUMMINS MARINE ENGINE NTA855-D(M) SO13019
CUMMINS MARINE ENGINE NTA855-D(M) SO13051
CUMMINS MARINE ENGINE NT855-M SO13058
CUMMINS MARINE ENGINE NTA855-D(M) SO13065
CUMMINS MARINE ENGINE NTA855-D(M)1 SO13812
CUMMINS MARINE ENGINE NTA855-M SO13096
CUMMINS MARINE ENGINE NTA855-D(M) SO13140
CUMMINS MARINE ENGINE NTA855-D(M) SO13821
CUMMINS MARINE ENGINE NTA855-M SO13273
CUMMINS MARINE ENGINE NT855-Mb3 SO13810
CUMMINS MARINE ENGINE NT855-Mb1 SO13806
CUMMINS MARINE ENGINE NTA855-Mb1 SO13805
CUMMINS MARINE ENGINE NTA855-Mb2 SO13800
CUMMINS MARINE ENGINE NTA855-D(M) SO13396
CUMMINS MARINE ENGINE NT855-Mb2 SO13809
CUMMINS MARINE ENGINE NT855-Mb1 SO13804
CUMMINS MARINE ENGINE NT855-D(M) SO13434
CUMMINS MARINE ENGINE NT855-D(M) SO13816
CUMMINS MARINE ENGINE NTA855-M SO13458
CUMMINS MARINE ENGINE NTA855-D(M) SO13471
CUMMINS MARINE ENGINE NTA855-D(M) SO13490
CUMMINS MARINE ENGINE NTA855-D(M)3 SO13813
CUMMINS MARINE ENGINE NTA855-D(M) SO13495
CUMMINS MARINE ENGINE NTA855-M SO13520
CUMMINS MARINE ENGINE NTA855-Mb2 SO13799
CUMMINS MARINE ENGINE NTA855-M SO13496
CUMMINS MARINE ENGINE NTA855-Mb3 SO13711
CUMMINS MARINE ENGINE NT855-M SO13752
CUMMINS MARINE ENGINE NTA855-M SO13753
CUMMINS MARINE ENGINE NTA855-M SO13754
CUMMINS MARINE ENGINE NTA855-M SO13755
CUMMINS MARINE ENGINE N855-DM SO13714
CUMMINS MARINE ENGINE N855-M SO13715
CUMMINS MARINE ENGINE N855-M SO13716
CUMMINS MARINE ENGINE N855-M SO13717
CUMMINS MARINE ENGINE N855-DM SO13718
CUMMINS MARINE ENGINE N855-DM SO13719
CUMMINS MARINE ENGINE N855-DM SO13778
CUMMINS MARINE ENGINE N855-DM SO13783
CUMMINS MARINE ENGINE N855-DM SO13792
CUMMINS MARINE ENGINE N855-DM SO13720
CUMMINS MARINE ENGINE N855-DM SO13738
CUMMINS MARINE ENGINE N855-DM SO13721
CUMMINS MARINE ENGINE N855-DM2 SO13817
CUMMINS MARINE ENGINE KTA19-M SO40001
CUMMINS MARINE ENGINE KTA19-M SO40465
CUMMINS MARINE ENGINE KTA19-M SO40002
CUMMINS MARINE ENGINE KTA19-M SO40470
CUMMINS MARINE ENGINE KTA19-M SO40467
CUMMINS MARINE ENGINE KTA19-D(M) SO40008
CUMMINS MARINE ENGINE KT19-M SO40021
CUMMINS MARINE ENGINE KTA19-M3 SO40028
CUMMINS MARINE ENGINE KTA19-M3 SO40471
CUMMINS MARINE ENGINE KTA19-M SO40036
CUMMINS MARINE ENGINE KTA19-D(M) SO40038
CUMMINS MARINE ENGINE KTA19-M3 SO40044
CUMMINS MARINE ENGINE KTA19-M4 SO40077
CUMMINS MARINE ENGINE KTA19-D(M) SO40163
CUMMINS MARINE ENGINE KTA19-D(M) SO40168
CUMMINS MARINE ENGINE KTA19-D(M) SO40185
CUMMINS MARINE ENGINE KTA19-M SO40197
CUMMINS MARINE ENGINE KTA19-Mb3  SO40201
CUMMINS MARINE ENGINE KTA19-Mb2 SO40496
CUMMINS MARINE ENGINE KTA19-D(M) SO40249
CUMMINS MARINE ENGINE KTA19-D(M) SO40259
CUMMINS MARINE ENGINE KTA19-D(M) SO40260
CUMMINS MARINE ENGINE KTA19-D(M) SO40261
CUMMINS MARINE ENGINE KTA19-D(M) SO40274
CUMMINS MARINE ENGINE KTA19-D(M) SO40515
CUMMINS MARINE ENGINE KT19-M SO40301
CUMMINS MARINE ENGINE KT19-M SO40447
CUMMINS MARINE ENGINE KT19-Mb2 SO40490
CUMMINS MARINE ENGINE KT19-Mb1  SO40485
CUMMINS MARINE ENGINE KTA19-M SO40303
CUMMINS MARINE ENGINE KT19-Mb1  SO40486
CUMMINS MARINE ENGINE KTA19-Mb3 SO40502
CUMMINS MARINE ENGINE KTA19-MB1 SO40504
CUMMINS MARINE ENGINE KTA19-M3 SO40370
CUMMINS MARINE ENGINE KTA19-Mb3 SO40501
CUMMINS MARINE ENGINE KTA19-Mb1 SO40493
CUMMINS MARINE ENGINE KTA19-Mb2 SO40489
CUMMINS MARINE ENGINE KTA19-Mb1 SO40512
CUMMINS MARINE ENGINE KTA19-M3 SO40379
CUMMINS MARINE ENGINE KT19-Mb3 SO40499
CUMMINS MARINE ENGINE KT19-Mb2 SO40503
CUMMINS MARINE ENGINE KT19-Mb1 SO40492
CUMMINS MARINE ENGINE KTA19-D(M) SO40412
CUMMINS MARINE ENGINE K19-M SO40415
CUMMINS MARINE ENGINE K19-M SO40416
CUMMINS MARINE ENGINE K19-M SO40417
CUMMINS MARINE ENGINE K19-M SO40418
CUMMINS MARINE ENGINE K19-DM SO40419
CUMMINS MARINE ENGINE K19-DM SO40420
CUMMINS MARINE ENGINE K19-DM SO40421
CUMMINS MARINE ENGINE K19-DM SO40482
CUMMINS MARINE ENGINE K19-DM SO40422
CUMMINS MARINE ENGINE K19-DM SO40456
CUMMINS MARINE ENGINE K19-DM SO40423
CUMMINS MARINE ENGINE K19-DM SO40478
CUMMINS MARINE ENGINE K19-DM SO40424
CUMMINS MARINE ENGINE K19-DM SO40495
CUMMINS MARINE ENGINE K19-DM SO40488
CUMMINS MARINE ENGINE K19-M SO40433
CUMMINS MARINE ENGINE K19-DM SO40434
CUMMINS MARINE ENGINE K19-M SO40436
CUMMINS MARINE ENGINE K19-M SO40437
CUMMINS MARINE ENGINE KTA19-D(M)1 SO40509
CUMMINS MARINE ENGINE KTA19-D(M)3 SO40511
CUMMINS MARINE ENGINE KT38-M SO60008
CUMMINS MARINE ENGINE KT38-D(M) SO60116
CUMMINS MARINE ENGINE KTA38-D(M) SO60117
CUMMINS MARINE ENGINE KT38-D(M) SO60132
CUMMINS MARINE ENGINE KTA38-M0 SO60135
CUMMINS MARINE ENGINE KTA38-M1 SO60155
CUMMINS MARINE ENGINE KTA38-D(M) SO60164
CUMMINS MARINE ENGINE KT38-M SO60170
CUMMINS MARINE ENGINE KT38-D(M) SO60173
CUMMINS MARINE ENGINE KTA38-D(M) SO60174
CUMMINS MARINE ENGINE KTA38-D(M) SO60175
CUMMINS MARINE ENGINE KT38-D(M) SO60176
CUMMINS MARINE ENGINE KTA38-D(M) SO60177
CUMMINS MARINE ENGINE KTA38-D(M)2 SO60396
CUMMINS MARINE ENGINE KTA38-D(M) SO60178
CUMMINS MARINE ENGINE KTA38-D(M) SO60179
CUMMINS MARINE ENGINE KTA38-M2 SO60180
CUMMINS MARINE ENGINE KTA38-Mb3 SO60397
CUMMINS MARINE ENGINE KTA38-MB1 SO60406
CUMMINS MARINE ENGINE KTA38-M2 SO60328
CUMMINS MARINE ENGINE KTA38-Mb3 SO60270
CUMMINS MARINE ENGINE KT38-D(M) SO60280
CUMMINS MARINE ENGINE KT38-Mb1 SO60384
CUMMINS MARINE ENGINE KT38-Mb2 SO60390
CUMMINS MARINE ENGINE K38-DM SO60289
CUMMINS MARINE ENGINE K38-DM SO60290
CUMMINS MARINE ENGINE K38-DM SO60291
CUMMINS MARINE ENGINE K38-DM SO60292
CUMMINS MARINE ENGINE K38-DM SO60334
CUMMINS MARINE ENGINE K38-M SO60293
CUMMINS MARINE ENGINE K38-M SO60294
CUMMINS MARINE ENGINE KTA38-D(M) SO60296
CUMMINS MARINE ENGINE K38-M SO60298
CUMMINS MARINE ENGINE K38-M SO60300
CUMMINS MARINE ENGINE K38-DM SO60301
CUMMINS MARINE ENGINE K38-M SO60303
CUMMINS MARINE ENGINE K38-M SO60305
CUMMINS MARINE ENGINE K38-M SO60306
CUMMINS MARINE ENGINE K50-M SO60344
CUMMINS MARINE ENGINE K50-M  SO60345
CUMMINS MARINE ENGINE K50-DM  SO60346
CUMMINS MARINE ENGINE K50-DM  SO60347
CUMMINS MARINE ENGINE K50-DM  SO60359
CUMMINS MARINE ENGINE K50-M  SO60348
