Heavy Duty Double Galvanized J Hook, wire hook

Product Overview

Description

Heavy Duty Double J Hook
Different WLL, Different Breaking Strength.
Different surface treatment

Type of Finish:

1.Galvanized

2.P.E Coated

3.Environmental protection coating



you can find below specification and other relative products in different specification,

Type of Finish:

1.Galvanized

2.P.E Coated

3.P.V.C Coated

4.Galvanized+1/2PVC coated

5.Galvanized+Full PVC coated

6.Galvanized+1/2 plastic Injection

7. painted



ITEM NO	A	B	C	D	E	BS
A700	108	76	32	20	121	10000KGS
A5000-84.6	75	51	24	20	84.6	5000KGS
A5001C	74	50.5	24	20	107	5000KGS
A5000-81	72	48	24	20	81	5000KGS
A2004	71	51	20	18	76	3000KGS
A2003	67	47	20	23	81.5	3000KGS
A2001-1	68.6	54	14.6	25	69	1500KGS
A2007	62	48	14	26	76	1500KGS
A1001	43	27	16	20	78	1500KGS
A1003	42	30	13	10	49.5	1600KGS
A1005	35	25.4	10	19	65.5	500KGS
A2006	59	45.4	14	/	42	1500KGS
A1002	40	26	14	10	47	1600KGS
A5000-74	76	52	24	25	74	5000KGS
A2001	72	52	20	25	86	3000KGS
A2002	72.5	51.5	21	32	85	2500KGS
A3001	60	40	20	22	86	3000KGS
A1002-1	40	26	14	18	60	1500KGS
A5000-78	75	52	24	25.4	78.8	5000KGS
A1004	35	25.5	10	7.2	42.1	230KGS
A1007	41	27	14	13	50	800KGS
A1009	43.5	30.5	13	10	49.3	1200KGS
A1010	40	26	14	19	57	1000KGS
A2001C	72	52	20	32	86	2500KGS
A2005	68	52	16	24	88	1700KGS
A2008	57	38	19	16	85	3000KGS
A3002	74	48	26	24	100	6500KGS
A3003	80	52.5	28	21	98	7000KGS
A3004	51	37	14	11	51	1500KGS
A5000-125	80	54	26	13	125	5000KGS
