DEUTZ ENGINE F2L912 F3L912 F4L912 F6L912 for concrete pump

Product Overview

Description

SHANGHAI STONE DIESEL ENGINE CO.,LTD SUPPLY DEUTZ ENGINE F2L912 F3L912 F4L912 F6L912 for concrete pump



Engine Type Cyl No.and Arrangement Bore/Stroke  (mm) Delivery capacity(L) Cooling  system and stroke Air-intake way Power/Rev  (kw/rpm)

DEUTZ DIESEL ENGINE  F2L912 2-cylinder in-line engines 100/120 1.88 Air-cooled vertical 4-stroke Naturally intake 14/1500 17/1800 20/2300

DEUTZ DIESEL ENGINE  F3L912 3-cylinder in-line engines 100/120 2.828 Air-cooled vertical 4-stroke Naturally intake 24/1500 29/1800 36/2300 38/2500

DEUTZ DIESEL ENGINE  F4L912 3-cylinder in-line engines 100/120 3.77 Air-cooled vertical 4-stroke Naturally intake 32/1500 38/1800 46/2300 51/2500

DEUTZ DIESEL ENGINE  F4L912T 3-cylinder in-line engines 100/120 3.77 Air-cooled vertical 4-stroke Turbo charged 41/1500 48/1800 52/2000

DEUTZ DIESEL ENGINE  F4L913 4-cylinder in-line engines 102/125 4.086 Air-cooled vertical 4-stroke Naturally intake 34/1500 40/1800 50/2300 56/2500

DEUTZ DIESEL ENGINE  BF4L913 4-cylinder in-line engines 102/125 4.086 Air-cooled vertical 4-stroke Turbo charged 47/1500 55/1800 66/2300 78/2500

DEUTZ DIESEL ENGINE  F6L912 6-cylinder in-line engines 100/120 5.655 Air-cooled vertical 4-stroke Naturally intake 48/1500 60/1800 74/2300 78/2500

DEUTZ DIESEL ENGINE  F6L912T 6-cylinder in-line engines 100/120 5.655 Air-cooled vertical 4-stroke Turbo charged 61/1500 72/1800 81/2300 85/2500

DEUTZ DIESEL ENGINE  F6L913 6-cylinder in-line engines 102/125 6.128 Air-cooled vertical 4-stroke Naturally intake 51/1500 65/1800 79/2300 85/2500

DEUTZ DIESEL ENGINE  BF6L913 6-cylinder in-line engines 102/125 6.128 Air-cooled vertical 4-stroke Turbo charged 74/1500 88/1800 112/2300 118/2500

DEUTZ DIESEL ENGINE  BF6L913C 6-cylinder in-line engines 102/125 6.128 Air-cooled vertical 4-stroke Charge inter-cooled 84/1500 105/1800 125/2300 141/2500

DEUTZ DIESEL ENGINE  F3L912W DEUTZ DIESEL ENGINE  F4L912W DEUTZ DIESEL ENGINE  F6L912W

Deutz B/F/L912/913/C series air-cooling diesel engine
Engine Type	Cyl No.and Ar- rangement	Bore/Stroke (mm)	Displacement (L)	Cooling  system and stroke	Air-intake way	Power/Rev  (kw/rpm)
F2L912	2-cylinder in-line	100/120	1.88	Air-cooled 4-stroke	Naturally intake	14/1500	17/1800	20/2300
F3L912	3-cylinder in-line	100/120	2.828	Air-cooled 4-stroke	Naturally intake	24/1500	29/1800	36/2300	38/2500
F4L912	4-cylinder in-line	100/120	3.77	Air-cooled 4-stroke	Naturally intake	32/1500	38/1800	46/2300	51/2500
F4L912T	4-cylinder in-line	100/120	3.77	Air-cooled 4-stroke	Turbo charged	41/1500	48/1800	52/2000
F4L913	4-cylinder in-line	102/125	4.086	Air-cooled 4-stroke	Naturally intake	34/1500	40/1800	50/2300	56/2500
BF4L913	4-cylinder in-line	102/125	4.086	Air-cooled 4-stroke	Turbo charged	47/1500	55/1800	66/2300	78/2500
F6L912	6-cylinder in-line	100/120	5.655	Air-cooled 4-stroke	Naturally intake	48/1500	60/1800	74/2300	78/2500
F6L912T	6-cylinder in-line	100/120	5.655	Air-cooled 4-stroke	Turbo charged	61/1500	72/1800	81/2300	85/2500
F6L913	6-cylinder in-line	102/125	6.128	Air-cooled 4-stroke	Naturally intake	51/1500	65/1800	79/2300	85/2500
BF6L913	6-cylinder in-line	102/125	6.128	Air-cooled 4-stroke	Turbo charged	74/1500	88/1800	112/2300	118/2500
BF6L913C	6-cylinder in-line	102/125	6.128	Air-cooled 4-stroke	Turbo charged cooling	84/1500	105/1800	125/2300	141/2500
F3L912W	3-cylinder in-line	100/120	2.828	Air-cooled 4-stroke	Naturally intake	29/2150	31/2300	33/2500
F4L912W	4-cylinder in-line	100/120	3.77	Air-cooled 4-stroke	Naturally intake	39/2150	42/2300	44/2500
F6L912W	6-cylinder in-line	100/120	5.655	Air-cooled 4-stroke	Naturally intake	60/2150	63/2300	66/2500
